Server Technology PRO2 C2S36CE-DFME2M66 36-Outlets PDU

Monitored - CS8365 3P+G 50A - 24 x IEC 60320 C13, 12 x IEC 60320 C19 - 230 V AC - Network (RJ-45) - Rack-mountable, Cabinet-mountable

SKU
C2S36CE-DFME2M66
Category
PDUs

MSRP$2,896.00

$2,732.80

Save 6%
Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Server Technology through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
C2S36CE-DFME2M66
Category
PDUs

Overview

The Server Technology® PRO2 Smart PDU provides local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS® technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO2 Smart "Master" PDU can be connected to as many as three (with optional module) PRO2 Smart "Link" PDU to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration.

Highlights

  • PDU distributes AC power to multiple servers and balances the load on the servers
  • Remotely monitor single-or-three phase voltage, frequency even load levels with monitored PDUs
  • IEC 60320 C13 receptacle type to ensure maximum usability and reliable power output
  • Three Phase phase PDU provides dependable power output with maximum efficiency
  • CS8365 3P+G 50A plug/connector type for efficient connectivity and feasible power output
  • 230 V AC input voltage for better reliance and maximum dependability

Specifications

Package Contents
  • PRO2 C2S36CE-DFME2M66 36-Outlets PDU
  • Button Mounts
  • Mounting Brackets
Product TypePDU
Input Voltage230 V AC
Manufacturer Part NumberC2S36CE-DFME2M66
Limited Warranty2 Year
Input Current50 A
ManagementHTTP/HTTPS TLSv1.2, SSHv2 Telnet SNMPv2c IPv4 IPv6 LDAPv3/LDAPS TACACS+ RADIUS FTP/SFTP v3: GET SET Traps
ManufacturerLegrand Group
Product ModelC2S36CE-DFME2M66
Product NamePRO2 C2S36CE-DFME2M66 36-Outlets PDU
Mount TypeRack-mountable, Cabinet-mountable
Protection TypeDouble Pole, Overload Protection, Circuit Protection
Product SeriesPRO2
Brand NameServer Technology
Plug/Connector TypeCS8365 3P+G 50A
Country of OriginUnited States
Height70"
Width2.2"
Depth2.5"
PhaseThree Phase
Receptacle TypeIEC 60320 C13, IEC 60320 C19
Network (RJ-45)Yes
PDU TypeMonitored
Power Rating (Watt)14.40 kW
Receptacle Detail24 x IEC 60320 C13, 12 x IEC 60320 C19
