Lantronix Compact 1-Port Secure Serial (RS232/ RS422/ RS485) to IP Ethernet Device Server and Modbus Support (TCP; ASCII; RTU); Up to 256-bit AES encryption; International 110 - 240 VAC
Lantronix

Lantronix Compact 1-Port Secure Serial (RS232/ RS422/ RS485) to IP Ethernet Device Server and Modbus Support (TCP; ASCII; RTU); Up to 256-bit AES encryption; International 110 - 240 VAC

Secure; Integrated; Plug-and-play Serial (RS232/RS422/RS85) to Ethernet Converter using Serial-over-IP technology; Modbus TCP; Modbus ASCII; Modbus RTU support; 128/192/256-bit AES encryption; Extended Temperature (-40 C to +85 C); Built-in HTTP Server; One DB-9 Serial Port; One 10/100 Mbps Fast Ethernet RJ-45 Port

SKU
XDT4851002IA-01-S
Category
Terminal & Device Servers

MSRP$123.14

$115.33

Save 6%
Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Lantronix through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
XDT4851002IA-01-S
Category
Terminal & Device Servers

Overview

Portable & Flexible

With an integrated Ethernet port and serial cable, multiple power options including PoE, and an industry-best five year warranty, the xDirect-IAP device server provides a portable, extremely flexible, and highly affordable network connectivity solution.

Robust & Easy

With plug-and-play simplicity, small form factor, multiple power options, and a robust device server application, xDirect-IAP provides the easiest and shortest path to network connectivity 'right on the wire'.

Specifications

Package Contents
  • xDirect 485 Device Server
  • 100-240 VAC International Power Supply with Regional Adapters
Product TypeDevice Server
Input Voltage120 V AC, 230 V AC
Manufacturer Part NumberXDT4851002IA-01-S
Limited Warranty5 Year
Standard Memory256 KB
Weight (Approximate)2.40 oz
ManufacturerLantronix, Inc
Product NamexDirect 485 Device Server
Product LinexDirect
Brand NameLantronix
Memory TechnologySRAM
Height1.1"
Width1.3"
Depth9.5"
Network Standard10/100Base-TX
Environmentally FriendlyYes
Wireless LANNo
Ethernet TechnologyFast Ethernet
USBNo
Number of Network (RJ-45) Ports1
Network (RJ-45)Yes
Serial PortYes
Parallel PortNo
Network (RJ-11)No
Management PortNo
Phone Line (RJ-11)No
Media Type SupportedTwisted Pair
Number of Serial Ports1
PoE (RJ-45) PortNo
Centronics PortNo
Environmental ComplianceRestriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE)
