Transition Networks Stand-alone Fiber to Fiber Media Converter
2 x SC Ports - Multi-mode - 850 nm Fiber - Gigabit Ethernet - 1000Base-SX, 1000Base-LX - 125 km - AC/DC - Wall Mountable, Standalone, DIN Rail Mountable
- SKU
- SFMFF1314-220-BR
- Category
- Transceivers/Media Converters
MSRP$1,403.00
$1,018.05
Save 27%Back ordered — ships when restocked.
Genuine Lantronix through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- SFMFF1314-220-BR
- Category
- Transceivers/Media Converters
Overview
The SFMFF1314-220 stand-alone, when used individually or in pairs, functions as a mode converter that extends Gigabit Ethernet or Fiber Channel signals over single mode fiber up to 125 kilometers. The SFMFF1314-220 also converts 1000Base-SX ports on a Gigabit Ethernet switch to 1000Base-LX on a port-by-port basis.
Highlights
- Auto-Negotiation (1000Base-X ports)
- Link Pass Through
- Pause
- Automatic Link Restoration
- Protocol Transparency
Specifications
| Package Contents |
|
|---|---|
| Product Type | Transceiver/Media Converter |
| Manufacturer Part Number | SFMFF1314-220-BR |
| Maximum Distance Supported | 125 km |
| Packaged Quantity | 1 |
| Power Source | AC/DC |
| Limited Warranty | Lifetime |
| Weight (Approximate) | 2 lb |
| Form Factor | Wall Mountable, Standalone, DIN Rail Mountable |
| Manufacturer | Lantronix, Inc |
| Product Model | SFMFF1314-220 |
| Product Name | Stand-alone Fiber to Fiber Media Converter |
| Network Technology | 1000Base-SX, 1000Base-LX |
| Brand Name | Transition Networks |
| Height | 1" |
| Width | 3.3" |
| Depth | 4.7" |
| Environmentally Friendly | Yes |
| Ethernet Technology | Gigabit Ethernet |
| Number of SC Ports | 2 |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Multi-mode |
| Total Number of Ports | 2 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Fiber Optic Cable Core/Cladding Specification | 62.5/125 µm, 50/125 µm |
| Fiber Optic Cable Wavelength | 850 nm |
