Tripp Lite by Eaton series 48V Extended Battery Module (EBM) for 750VA, 1000VA and 1500VA SmartPro UPS Systems, 2U Rack/Tower
48 V DC - Lead Acid - Valve-regulated/User Replaceable - Hot Swappable
- SKU
- BP48VRM2U
- Category
- UPS Batteries
MSRP$1,225.35
$773.92
Save 37%In stock: 393
Genuine Eaton through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- BP48VRM2U
- Category
- UPS Batteries
Overview
Features | Backup Battery Module Gives Your Compatible Eaton UPS System Extended Runtime
The BP48VRM2U offers extended battery runtime when used in conjunction with Eaton Tripp Lite series 750VA, 1000VA and 1500VA SmartPro® UPS systems. It can also be daisy-chained for a maximum of four matching battery packs to deliver even longer extended-run operation. Heavy-gauge cabling with high-current DC connectors is included for safe, simple installation.
Supports 2U Rack or Tower Installation
This backup battery pack's multi-use form factor supports mounting in 2U of space in EIA-standard 19- inch open frame racks or enclosures using the included 4-post rail kit and mounting brackets. Tower stands are also included for optional upright configuration. More from the Manufacturer
Extended Battery Modules for Eaton Tripp Lite Series UPS Systems
An ideal solution for extended-run operation
The BP48VRM2U rack/tower external battery pack extends battery runtime when used with compatible Eaton Tripp Lite series 750VA, 1000VA and 1500VA SmartPro UPS Systems. An included daisy-chain connector allows the addition of up to four matching battery packs per UPS for even longer extended-run operation. To ensure safe and simple installation, heavy-gauge cabling with high-current DC connectors is also included.
Innovative features for premium performance
Versatile installation
The BP48VRM2U’s multi-use form factor supports both rack-mount and tower installation, allowing you to place the battery where you need it most.
Mounts in 2U of space in EIA-standard 19-inch racks or enclosures using the included 4-post mounting brackets.
Tower stands are included for optional upright configuration.
Optional 2-post rack-mount or wall adapter kit (2POSTRMKITWM or UPSHDEARKIT, sold separately) supports 2-post rack or wall-mount installation.
Broad compatibility
This 48V external battery pack is designed for select SmartPro line-interactive UPS systems.
120V model compatibility: SMART750RMXL2U, SMART750RMXL2UN, SMART1000RMXL2U, SMART1000RMX2UN, SMART1500RMXL2U and SMART1500RMXLN
208V/230V model compatibility: SMX1500XLRT2U and SMX1500XLRT2UN
Optional use rear-panel battery detection jacks automatically configure host UPS systems supporting this feature.
Warranty
Limited Warranty: 1 Year
About Eaton
Eaton is an intelligent power management company dedicated to improving the quality of life and protecting the environment for people everywhere. We are guided by our commitment to do business right, to operate sustainably and to help our customers manage power ─ today and well into the future. By capitalizing on the global growth trends of electrification and digitalization, we're accelerating the planet's transition to renewable energy and helping to solve the world's most urgent power management challenges.
Highlights
- Connects to select expandablebEaton Tripp Lite series UPS systems for extended runtime
- Daisy-chain connector supports additional battery packs for even longer runtime
- Includes heavy-gauge cabling with high-current 48V DC connectors
- Supports 2U rack mounting or upright tower installation using included accessories
Specifications
| Battery Chemistry | Lead Acid |
|---|---|
| Package Contents |
|
| Product Type | UPS Battery Pack |
| Compatibility | Tripp Lite UPSes: SMART750RMXL2U SMART750RMXL2UN SMART1000RMXL2U SMART1000RMX2UN SMART1500RMXL2U SMART1500RMXLN SMX1500XLRT2U SMX1500XLRT2UN |
| Hot Swappable | Yes |
| Manufacturer Part Number | BP48VRM2U |
| Limited Warranty | 1 Year |
| Output Voltage | 48 V DC |
| Manufacturer | Eaton Corporation |
| Product Model | BP48VRM2U |
| Product Name | Extended Battery Modules BP48VRM2U UPS Battery Pack |
| Product Series | Extended Battery Modules |
| Brand Name | Tripp Lite series |
| Country of Origin | Philippines |
| Height | 3.4" |
| Width | 17.2" |
| Depth | 17.6" |
| Environmentally Friendly | Yes |
| Battery Characteristics | Valve-regulated/User Replaceable |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
