Eaton Tripp Lite Series 36V Extended Battery Module (EBM) for SmartOnline UPS Systems, 2U Rack/Tower
Eaton

Eaton Tripp Lite Series 36V Extended Battery Module (EBM) for SmartOnline UPS Systems, 2U Rack/Tower

36 V DC - Lead Acid - Valve-regulated/User Replaceable - Hot Pluggable

SKU
BP36RT
Category
UPS Batteries

MSRP$1,144.00

$713.15

Save 38%

In stock: 143

Get a quote

Genuine Eaton through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
BP36RT
Category
UPS Batteries

Overview

Provides extended runtime for compatible UPS systems in education, healthcare, military, government and other IT applications in small or mid-size networks.

Features | Backup Battery Module Gives Your Compatible UPS System Extended Runtime

The valve-regulated lead-acid (VRLA) BP36RT offers extended battery runtime when used in conjunction with SU750RTXLCD2U, SU750RTXLCD2UN, SU1000RTXLCD2U and SU1000RTXLCD2UN SmartOnline® UPS systems. It can also be daisy-chained for a maximum of four matching battery packs to deliver even longer extended-run operation. Heavy-gauge cabling with high-current DC connectors is included for safe, simple installation.

Versatile Installation Options

You can mount the BP36RT in 2U of space in an EIA-standard 19-inch rack using the included 4-post rail kit or an optional 2-post rail kit (RK2PC, sold separately). You can also adapt it for tower installation using the UPS system's support stands.

Warranty

Limited Warranty: 2 Year

About Eaton

Eaton is an intelligent power management company dedicated to improving the quality of life and protecting the environment for people everywhere. We are guided by our commitment to do business right, to operate sustainably and to help our customers manage power ─ today and well into the future. By capitalizing on the global growth trends of electrification and digitalization, we're accelerating the planet's transition to renewable energy and helping to solve the world's most urgent power management challenges.

Highlights

  • Connects to select expandable Tripp Lite series SmartOnline UPS systems to add critical runtime
  • Includes heavy-gauge battery cabling with high-current 36V DC connectors
  • Daisy-chain connector supports additional battery packs for even longer runtime

Specifications

Battery ChemistryLead Acid
Package Contents
  • Extended Battery Module BP36RT UPS Battery Pack
  • External Battery Cable
  • Rack-Mounting Hardware
  • Quick Start Guide
Product TypeUPS Battery Pack
CompatibilityTripp Lite UPSes: SU750RTXLCD2U SU750RTXLCD2UN SU1000RTXLCD2U SU1000RTXLCD2UN
Manufacturer Part NumberBP36RT
Limited Warranty2 Year
Output Voltage36 V DC
Weight (Approximate)48.10 lb
ManufacturerEaton Corporation
Product ModelBP36RT
Product NameExtended Battery Module BP36RT UPS Battery Pack
Product SeriesExtended Battery Modules
Brand NameTripp Lite series
Country of OriginPhilippines
Height3.4"
Width17.3"
Depth17.7"
Environmentally FriendlyYes
Hot PluggableYes
Battery CharacteristicsValve-regulated/User Replaceable
Environmental ComplianceRegistration, Evaluation, Authorization and Restriction of Chemicals (REACH), Restriction of Hazardous Substances (RoHS)
