Black Box KVX Series KVM Extender Kit over Fiber - DVI-D, USB 2.0, Serial, Audio, Local Video
Black Box

Black Box KVX Series KVM Extender Kit over Fiber - DVI-D, USB 2.0, Serial, Audio, Local Video

65616.80 ft Range - 1920 x 1200 Maximum Video Resolution - 5 x USB - 6 x DVI - 5 V DC Input Voltage - TAA Compliant

SKU
KVXLCF-200-SFPBN3-R2
Category
KVM Consoles/Extenders

MSRP$1,679.43

$1,313.45

Save 22%
Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Black Box through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
KVXLCF-200-SFPBN3-R2
Category
KVM Consoles/Extenders

Overview

The KVX DVI-D KVM Extender lets you control a server or computer over single-mode or multimode cable at distances of up to 30 km (depending on the SFP used, fiber type, and fiber bandwidth). Single-monitor requires one fiber connection and dual-monitor requires two fiber connections. PC connection cables are included with this product, making it a solution that is ready to use right out of the box.

You can use your existing keyboard, mouse, and monitor to access both the server room and your office computer, saving space and avoiding the need for a dedicated remote console. Available with support for one or two monitors, KVX Dual Head is the perfect low-cost solution for transportation control centers, medical facilities, industrial warehouses, and extended workstations.

KVX is equipped with an RS-232 serial channel that connects to a serial terminal or to serial devices, such as touchscreens and barcode scanners. It eliminates the need for traveling back and forth between the local computer and remote console, making it an efficient and flexible solution.

KVX also includes local video, allowing access to an additional monitor at the transmitter side. It's perfect for any situation that requires monitoring of connected PCs.

This extender is TAA compliant and backed by free lifetime technical support. KVX is ideal for applications that require the console to be in a conveniently accessible location while the system equipment needs to reside in a safe place - away from dust, dirt, and harsh environmental influences. It also provides a cost-effective way of keeping sensitive data, such as financial and personal information, safe in a heavily secured data center while still allowing remote access to users.

Highlights

  • Supports DVI-D video resolution up to 1920x1200 at 60 Hz
  • Local and remote units connect at distances of up to 30 km (depending on the SFP used, fiber type, and fiber bandwidth)
  • Transparent USB 2.0 extension supports HID devices, mass storage devices
  • Supports RS-232 peripheral (serial) devices
  • Bi-directional audio via speaker/mic connection
  • Local DVI port loopback for monitoring on transmitter (TX) unit
  • Supports EDID pass-through

Specifications

Package Contents(1) Transmitter (1) Receiver (2) 5V, 2A Power Supplies (Includes US, EU, AU & UK Plug types) (1) or (2) DVI-D Cables, Male/Male 1.8m (6 ft.) (1) USB Type A to B Cable, Male/Male 1.8m (6 ft.) (1) 3.5mm Dual Audio / Mic Cable, Male/Male 1.8m (6 ft.)
Product TypeKVM Extender
Input Voltage5 V DC
Manufacturer Part NumberKVXLCF-200-SFPBN3-R2
Connectivity TechnologyWired
ManufacturerBlack Box Corporation
Product NameKVX Series KVM Extender Kit over Fiber - DVI-D, USB 2.0, Serial, Audio, Local Video
Product SeriesKVX
Brand NameBlack Box
Maximum Video Resolution1920 x 1200
Maximum Operating Distance65616.80 ft
USBYes
DVIYes
Number of USB Ports5
Number of DVI Ports6
Transmitter Height1.71"
Transmitter Width7.09"
Transmitter Depth3.27"
Receiver Height1.71"
Receiver Width7.12"
Receiver Depth3.28"
Transmitter Weight (Approximate)1.12 lb
Receiver Weight (Approximate)1.12 lb
TAA CompliantYes
Device TypeKVM Extender
