B+B SmartWorx 10/100/1000Mbps Miniature Media Converter
1 x Network (RJ-45) - Gigabit Ethernet - 10/100/1000Base-TX - 2 x Expansion Slots - SFP (mini-GBIC) - 2 x SFP Slots - AC Adapter - Rail-mountable, Wall Mountable
- SKU
- IMC-370I-2SFP-PS
- Category
- Transceivers/Media Converters
MSRP$208.77
$169.24
Save 19%Back ordered — ships when restocked.
Genuine Advantech through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- IMC-370I-2SFP-PS
- Category
- Transceivers/Media Converters
Overview
The IMC-370 series offers the most compact media converters. They can extend the 10, 100 and 1000Mbps twisted-pair network segments up to 80km over fiber technology. Supporting both 10/100/1000Mbps auto negotiation on the copper port and 1000Mbps full-duplex on the fiber port, the IMC-370 series serves as a media and data rate converter.
The IMC-370I-SFP supports Link Fault Pass Through (LFPT) functionality which can be enabled/disabled by a DIP switch on the unit. This useful diagnostic feature assists the network administrator in indicating a fault condition on a given segment between the interfaces.
The IMC-370I supports plug-n-play functionality, auto negotiation, and AutoCross operation. It can be powered by AC/DC power, dual USB cable, or via installation in a centrally-powered media converter chassis.
Highlights
- Metal enclosure with compact size
- Industrial grade design that supports an extended operating temperature range (IMC-370I series)
- Provides status LED
- Supports multiple power options: AC or DC adapter and dual USB cable
- Supports Link Fault Pass Through (LFPT) (IMC-370I-SFP)
- Centralized powered IMC-318I chassis
Specifications
| Package Contents |
|
|---|---|
| Product Type | Transceiver/Media Converter |
| Manufacturer Part Number | IMC-370I-2SFP-PS |
| Power Source | AC Adapter |
| Weight (Approximate) | 11.18 oz |
| Form Factor | Rail-mountable, Wall Mountable |
| Manufacturer | Advantech Co., Ltd |
| Product Model | IMC-370I-2SFP-PS |
| Product Name | 10/100/1000Mbps Miniature Media Converter |
| Network Technology | 10/100/1000Base-TX |
| Product Series | IMC-370I |
| Brand Name | B+B SmartWorx |
| Expansion Slot Type | SFP (mini-GBIC) |
| Country of Origin | Taiwan |
| Height | 0.8" |
| Width | 1.8" |
| Depth | 3.4" |
| Environmentally Friendly | Yes |
| Ethernet Technology | Gigabit Ethernet |
| Number of Network (RJ-45) Ports | 1 |
| Network (RJ-45) | Yes |
| Number of SFP Slots | 2 |
| Media Type Supported | Twisted Pair, Optical Fiber |
| Total Number of Ports | 1 |
| Total Number of Expansion Slots | 2 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
