B+B SmartWorx IMC-350I 10/100Mbps Miniature Media Converter
Advantech

B+B SmartWorx IMC-350I 10/100Mbps Miniature Media Converter

1 x Network (RJ-45) - 1 x SC Ports - Single-mode (Bi-directional) - 1550 nm, 1310 nm Fiber - Fast Ethernet - 100Base-FX - 100 Mbit/s - 20 km - DC - Compact

SKU
IMC-350I-SST-B
Category
Transceivers/Media Converters

MSRP$193.61

$156.69

Save 19%
Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Advantech through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
IMC-350I-SST-B
Category
Transceivers/Media Converters

Overview

Mini Hardened Media Converter, 100Mbps, Single-Strand 1310xmt, LFPT, 20km, SC

• Centralized powered IMC-318I chassis

• Supports Link Fault Pass Through functionality (LFPT)

• IEEE802.3af compliant (IMC-350I series as PoE-PD)

• Industrial grade design that supports an extended operating temperature(IMC-350I series)

• Metal enclosure with compact size

Highlights

  • Metal enclosure with compact size
  • Industrial grade design that supports an extended operating temperature
  • NEMA TS2 for traffic control
  • Support multiport power options: AC or DC adapter and dual USB cable
  • IEEE802.3af compliant (as PoE-PD)
  • Supports Link Fault Pass Through (LFPT)
  • Support centralized powered IMC-318I chassis

Specifications

Product TypeTransceiver/Media Converter
Manufacturer Part NumberIMC-350I-SST-B
Maximum Distance Supported20 km
Power SourceDC
Weight (Approximate)10.58 oz
Form FactorCompact
ManufacturerAdvantech Co., Ltd
Product NameIMC-350I 10/100Mbps Miniature Media Converter
Network Technology100Base-FX
Product LineIE-MiniMc
Product SeriesIMC-350I
Brand NameB+B SmartWorx
Plug/Connector TypeTerminal Block
Height1.8"
Width0.8"
Depth3.4"
Maximum Data Transfer Rate100 Mbit/s
Ethernet TechnologyFast Ethernet
Number of Network (RJ-45) Ports1
Network (RJ-45)Yes
Number of SC Ports1
Media Type SupportedTwisted Pair, Optical Fiber
Fiber Mode SupportedSingle-mode (Bi-directional)
Total Number of Ports2
PoE Port TypePD
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
Fiber Optic Cable Wavelength1550 nm, 1310 nm
