Advantech IMC-310I-SFP Transceiver/Media Converter
1 x Network (RJ-45) - Single-mode, Multi-mode - 10 Gigabit Ethernet - 10GBase-X, 10GBase-T, 10GBase-LR, 100Base-TX, 1000Base-T, 2.5GBase-T, 5GBase-T, 10GBase-SR, 10GBase-ER, 10GBase-ZR - 80 km - 1 x Expansion Slots - SFP+ - 1 x SFP+ Slots - AC/DC - DIN Rail Mountable, Panel-mountable, Standalone
- SKU
- IMC-310I-SFP-A
- Category
- Transceivers/Media Converters
MSRP$509.49
$410.48
Save 19%Back ordered — ships when restocked.
Genuine Advantech through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- IMC-310I-SFP-A
- Category
- Transceivers/Media Converters
Overview
IMC-310I-SFP 10G Medial Converter is equipped with one 10G/5G/2.5G/1G/100M BASE-T auto-negotiation port and one 10GBASE-X SFP+ Slot. IMC-310I-SFP supports 10 x Gigabit Ethernet media converter from copper 10GBASE-T to fiber multi-mode or single-mode. It utilizes a 10BASE-SR or 10GBASE-LR SFP+ transceiver installed in the SFP+ slot to extend distances to servers, switches, and patch panels. IMC-310I-SFP supports transmission distance from 400m up to 80km to facilitate 10G equipment and device deployment.
Highlights
- Provides 1xRJ45 to 1xSFP/SFP+ fiber port
- Copper port interface supports 10G/5G/2.5G/1G/100M BASE-T
- Copper port provide full/half duplex flow control
- Supports store and forward transmission
- Supports MDI/MDI-X, auto-negotiation
- Supports AC/DC power input dual mode power input
- Provides flexible mounting: DIN-Rail and panel mount
- Link Fault Pass-Through (LFPT) for troubling shooting
- Fiber port distance from 400m up to 80km
Specifications
| Product Type | Transceiver/Media Converter |
|---|---|
| Manufacturer Part Number | IMC-310I-SFP-A |
| Maximum Distance Supported | 80 km |
| Power Source | AC/DC |
| Form Factor | DIN Rail Mountable, Panel-mountable, Standalone |
| Manufacturer | Advantech Co., Ltd |
| Product Model | IMC-310I-SFP |
| Product Name | IMC-310I-SFP Transceiver/Media Converter |
| Network Technology | 10GBase-X, 10GBase-T, 10GBase-LR, 100Base-TX, 1000Base-T, 2.5GBase-T, 5GBase-T, 10GBase-SR, 10GBase-ER, 10GBase-ZR |
| Brand Name | Advantech |
| Plug/Connector Type | Terminal Block (4 Wire), DC Jack |
| Expansion Slot Type | SFP+ |
| Height | 0.9" |
| Width | 4.3" |
| Depth | 4" |
| Ethernet Technology | 10 Gigabit Ethernet |
| Number of Network (RJ-45) Ports | 1 |
| Network (RJ-45) | Yes |
| Number of SFP+ Slots | 1 |
| Media Type Supported | Twisted Pair, Optical Fiber |
| Fiber Mode Supported | Single-mode, Multi-mode |
| Total Number of Ports | 1 |
| Total Number of Expansion Slots | 1 |
| Fiber Optic Cable Core/Cladding Specification | 50/125 µm, 62.5/125 µm, 9/125 µm |
