Zebra RS6100 Bluetooth Wearable Scanner
Zebra Technologies

Zebra RS6100 Bluetooth Wearable Scanner

Cable Connectivity - SE55Scan Engine - 1D, 2D - Laser - Imager - Bluetooth - IP65 - Warehouse, Distribution, Manufacturing, Transportation, Logistics, Retail

SKU
RS61B0-KNNTZWR
Category
Barcode Scanners

MSRP$1,256.10

$970.72

Save 23%
Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Zebra Technologies through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
RS61B0-KNNTZWR
Category
Barcode Scanners

Overview

Maximum versatility, power and performance

Introducing Zebra's most powerful and versatile wearable scanner-the RS6100. This small and practically weightless wearable scanner is less than half the size and weight of its predecessor, the RS6000. An advanced multi-focus scan engine captures 1D and 2D barcodes at close range and on the top shelf of a rack 40 ft./12.2 m away, regardless of condition-scratched, dirty, poorly printed, under shrinkwrap and more. With five interchangeable wearing options, there's a style that will maximize comfort for every user. Use it anywhere-from warehouse aisles, freezers and coolers to the seat of a fork truck and out on the dock in rain, snow, blazing summer heat or subzero winter cold. The RS6100 is always in service with its removable battery-no downtime needed for charging, just swap in a fully charged battery. Choose cordless freedom with two battery options or corded battery-free operation. And since the RS6100 and RS5100 share common trigger assemblies, batteries and mounts, upgrading from the RS5100 is easy and cost-effective.

Five Interchangeable Wearing Styles

Five different mounts provide users with the freedom to choose the wearing style they prefer to maximize comfort, simplify task execution-and increase job satisfaction. All mounting accessories are interchangeable-swap at any time to maximize user comfort for scan-intensive tasks. The Enterprise Hand Mount accessory gives every hand a snug, comfortable and secure custom fit with a range of sizes for right and left hands-and users can adjust the scanner position on the hand to achieve the perfect balance and optimal scan angle for the ultimate in comfort and user productivity. For workers who prefer to wear the scanner on one finger, there are two single finger mount options-single and double triggers. The single trigger can be removed and rotated, allowing users to easily switch between left and right finger mounting. The double trigger enables workers to change hands on the fly-without removing the trigger. All triggers support continuous scanning mode. And the optional vibrating trigger signals an error or exception, allowing users to take corrective actions. The ambidextrous, one-size-fits-all back of hand mount accommodates gloves and easily fits into the smallest of spaces. And a retracting lanyard trigger worn around the neck or on a belt keeps the scanner handy, yet out of the way

Use it Everywhere-Including The Freezer

Use the RS6100 in freezers and coolers, out on the dock in the sweltering heat and subzero cold, rain, snow-the RS6100 is built to handle it all.

Small and Practically Weightless

The RS6100 is less than half the size and weight of its predecessor, the RS6000-just over two ounces and two cubic inches.

Cordless or Corded-It's Your Choice

Pair with any Bluetooth-enabled Zebra enterprise-class handheld, tablet, wearable or vehicle mount mobile computer to utilize the full feature set of the RS6100-or pair with any existing Bluetooth smartphone, tablet or PC. Want to eliminate the need for batteries with corded operation? Power the RS6100 via a corded adapter that connects to select Zebra mobile devices, including wearable and handheld computers.

Instant Pairing-Just Tap and Go

With NFC, simply tap the RS6100 on NFC-enabled Zebra devices- no need to scan a pairing barcode or open Bluetooth settings to identify and select the device.

Direct Users With Programmable Line-of-Sight LEDs

Programmable multiple LEDs on the back of the RS6100 can provide users with feedback to improve productivity and task accuracy- confirm successful scans, direct users through the fastest path to the righ

Highlights

  • Allows productive and precise reading of 1D barcodes
  • Regardless of angle orientation, the imager makes it easy to scan 1D and 2D barcodes
  • With laser scanning technology you don't have to use any additional lighting as it works effectively in low ambient lighting conditions too
  • Wired connectivity makes this scanner ideal for retail and desktop applications
  • Bluetooth technology - Allows compatibility with most of your smart devices

Specifications

Application/UsageWarehouse, Distribution, Manufacturing, Transportation, Logistics, Retail
Barcode Symbology Supported1D: Code 39 Code 128 Code 93 Codebar/NW7 Code 11 MSI UPC/EAN I 2 of 5 Korean 3 of 5 GSI DataBar Base 32 (Italian Pharma) 2D: PDF417 Micro PDF417 Composite Codes TLC-39 Aztec DataMatrix MaxiCode QR Code Micro QR Chinese Sensible (Han Xin) Postal Codes OCR Symbologies: OCR-A OCR-B
Product TypeBarcode Scanner
Manufacturer Part NumberRS61B0-KNNTZWR
Limited Warranty1 Year
Connectivity TechnologyCable
Form FactorWearable
Length2.6"
ManufacturerZebra Technologies Corporation
Product ModelRS6100
Product NameRS6100 Bluetooth Wearable Scanner
Brand NameZebra
Light SourceLaser
Width1.3"
Depth0.8"
Environmentally FriendlyYes
BluetoothYes
Scanner RangeLong Range
Drop SpecificationMultiple 6 ft./1.8 m drops to concrete over the operating temperature range
Image Sensor TypeImager
Illumination TypeLED
Scan ModeTrigger
Storage Temperature-40°F (-40°C) to 140°F (60°C)
Illumination ColorWhite
Ingress Protection (IP) RatingIP65
RuggedYes
Scan Engine ModelSE55
Scanning Capability1D, 2D
Field of View (Horizontal)37°
Field of View (Vertical)21°
Reading Angle (Skew)60°
Reading Angle (Pitch)60°
Reading Angle (Roll)360°
Maximum Ambient Light107639 lux
Minimum Element Resolution (Code 39)3 mil
Maximum Element Resolution (Code 39)100 mil
Minimum Element Resolution (DataMatrix)10 mil
Maximum Element Resolution (DataMatrix)100 mil
Minimum Element Resolution (PDF417)5 mil
Maximum Element Resolution (PDF417)6.7 mil
Operating Temperature122°F (50°C)
Humidity (Non-condensing)5% to 95%
Environmental ComplianceRegistration, Evaluation, Authorization and Restriction of Chemicals (REACH), Restriction of Hazardous Substances (RoHS)
