Vertiv PowerIT VP1U60A2 Basic High Density rPDU, Vertical, Three Phase, 36 Combination C13/C19 Outlets, 60/63A, 240/415V WYE, 0U
Rack power distribution unit, 43.4kW, 3P+N+E (IP44) plug, TAA Compliance, RoHS, China RoHS, UL/CE dual listed, 3-year warranty extending to 5-year warranty if registered within 120 days of purchase
- SKU
- VP1U60A2
- Category
- PDUs
MSRP$3,054.00
$2,052.29
Save 33%Back ordered — ships when restocked.
Genuine Vertiv through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- VP1U60A2
- Category
- PDUs
Overview
The Vertiv PowerIT VP1U60A2 is a basic high density rack power distribution unit (rPDU). It is a 60/63A, 240/415V WYE, 0U, vertical rPDU with 36 Combination C13/C19 outlets that provide the flexibility to connect C14 and C20 plugs in the same outlet interchangeably. This unit also comes with a 3P+N+E (IP44) plug providing 43.4kW of power capacity. This model is UL/CE dual listed, meeting an important requirement for data centers. It is also RoHS-certified and individually tested for functionality to ensure your network is powered by a reliable power distribution unit. Plus, it includes a three-year warranty that is extendable to five years if registered within 120 days of purchase. More from the Manufacturer
VP1U60A2
Power Rating (kW)
43.4
Input Voltage
240/415V WYE
Combination C13/C19 Outlets
36
60°C Working Ambient
Variants
Yes
IMD-5M
No
Fault-Tolerant Daisy Chaining
No
Remote Control of Individual Outlet
No
Real-Time Monitoring and Remote Power Cycling
No
Vertiv Intelligence Director
No
VP4NA0A0
Power Rating (kW)
28.8
Input Voltage
1~ 240V/3~ 208V
Combination C13/C19 Outlets
24
60°C Working Ambient
Variants
Yes
IMD-5M
Yes
Fault-Tolerant Daisy Chaining
Yes
Remote Control of Individual Outlet
No
Real-Time Monitoring and Remote Power Cycling
Yes
Vertiv Intelligence Director
Yes
VP5UA0A0
Power Rating (kW)
57.6
Input Voltage
240V/415V WYE
Combination C13/C19 Outlets
36
60°C Working Ambient
Variants
Yes
IMD-5M
Yes
Fault-Tolerant Daisy Chaining
Yes
Remote Control of Individual Outlet
Yes
Real-Time Monitoring and Remote Power Cycling
Yes
Vertiv Intelligence Director
Yes
Warranty
Additional Warranty Information: 5-year limited warranty if registered within 120 days of purchase, otherwise warranty defaults to 3 years Limited Warranty: 5 Year
About Vertiv
Digital Continuity Solutions Vertiv brings together hardware, software, analytics, and ongoing services to ensure a customer’s digital infrastructure and vital applications run continuously, perform optimally, and scale with business needs Vertiv is a U.S. based, publicly-traded (NYSE: VRT), global manufacturer of power, thermal and IT infrastructure products and services. By bringing together hardware, software and on-going services, Vertiv offers solutions that ensure uninterrupted, reliable, safe operations of vital data applications that run continuously and perform-optimally. Vertiv possesses a rare combination of expertise and solutions that ensures connectivity and availability across any and all network facilities, anywhere in the world. Our portfolio includes the most respected brands in the industry including Avocent (networking and remote management), Geist (rack PDUs, monitors, sensors), and Liebert (UPS, power and thermal). Visit Vertiv.com for more information. Our Brands Avocent The power of being there When you need to take control of multiple IT devices across a room or across geographies, you can rely on market-leading Avocent or Cybex keyboard, video, and mouse (KVM) switches and serial consoles to provide easy, single-point access to valuable system data. Since 1981 Avocent has been developing and manufacturing industry-leading KVM switches and serial consoles to deliver easy, single-point access to valuable system data in order to control and simplify management of multiple IT devices. Vertiv’s Avocent solutions have helped over 200,000 customers worldwide by providing faster provisioning, simplified management, reduced mean time to repair, enhanced security, and lower operating costs. Geist Reliable power management Ensuring data center availability and business continuity requires that the last link in the power chain, the rack power distribution unit (rPDU), operates as intended to support dynamic operations in the areas of power, cooling, monitoring, and overall data center infrastructure management (DCIM). Geist designs and manufactures industry-leading technology and software to power, cool, monitor and manage critical data center infrastructure. On-site engineering, reliability, conformance and compliance allow us to design, manufacture, and ship PDUs so they arrive when you need them. Customers have peace of mind knowing Geist’s dedicated compliance and reliability engineering team ensure conformance to global standards for reliability, safety, and accuracy. Liebert Protecting the power and environment of your mission critical electronic systems Your data center and edge computing sites are the core of your business. Intelligent, efficient power and thermal infrastructure are critical to ensuring continuous access to vital applications and data. Liebert power and thermal management systems are designed to protect your IT environment and adapt to your changing needs. Liebert provides global power and thermal management solutions with a portfolio of most efficient and reliable power and cooling technologies in the market. Liebert offers a complete line of energy-efficient and reliable technologies including UPS, racks, rack enclosures, rack cooling, and PDUs. These award-winning technologies offer unmatched efficiency and reliability for mission-critical applications, as well as controls to optimize uptime. Architects of Continuity As Architects of Continuity, Vertiv solutions help customers build future-ready digital infrastructures that deliver continuity across large infrastructure (AC power, DC power, energy storage, industrial solutions, thermal) and IT and edge infrastructure (edge systems, IT systems, rack, rack PDU, rack thermal, rack UPS) applications. Customers can choose to work with a trusted Vertiv advisor or order products online via their preferred IT distributors, resellers and marketplaces. To learn more, visit Vertiv.com today!
Highlights
- Offers a reliable, space-saving, and cost-effective power distribution for all IT applications
- Connect both C14 and C20 plugs interchangeably via the Combination C13/C19 receptacle
- Secure connections with the high-retention, color-coded receptacle that is P-Lock cable-compatible
- Unit is tested to meet local compliance requirements: UL, CE, RoHS, China RoHS, and TAA
- Comes with a three-year warranty, extendable to five years if registered within 120 days of purchase
Specifications
| Additional Warranty Information | 5-year limited warranty if registered within 120 days of purchase, otherwise warranty defaults to 3 years |
|---|---|
| Product Type | PDU |
| Input Voltage | 230 V AC, 415 V AC |
| Manufacturer Part Number | VP1U60A2 |
| Limited Warranty | 5 Year |
| Output Voltage | 240 V AC |
| Form Factor | Rack |
| Input Current | 63 A |
| Length | 78" |
| Management | No |
| Manufacturer | Vertiv |
| Product Name | Basic VP1U60A2 PDU |
| Mount Type | Rack-mountable |
| Product Line | Geist Upgradeable |
| Protection Type | Overcurrent Protection |
| Product Series | G |
| Rack Height | 0U |
| Brand Name | Vertiv Geist |
| Plug/Connector Type | 3P+N+E (IP44) |
| Country of Origin | United States |
| Cord Length | 10 ft |
| Width | 2" |
| Depth | 2.6" |
| Phase | Three Phase |
| Receptacle Type | Combination C13/C19 |
| Network (RJ-45) | No |
| TAA Compliant | Yes |
| PDU Type | Basic |
| Remote Outlet Switching | No |
| Mounting Orientation | Vertical |
| Power Rating (Watt) | 43.40 kW |
| Product Color | Black |
| Color Family | Black |
| Receptacle Detail | 36 x Combination C13/C19 |
| Plug/Connector Detail | 1 x 3P+N+E (IP44) |
| Environmental Compliance | China Restriction of Hazardous Substances (China RoHS), Restriction of Hazardous Substances (RoHS) |
