QNAP TS-AI642-8G SAN/NAS Storage System
ARM Cortex A76 Quad-core (4 Core) 2.20 GHz - 6 x HDD Supported - 0 x HDD Installed - 6 x SSD Supported - 0 x SSD Installed - 8 GB RAM DDR4 SDRAM - Serial ATA/600 Controller - RAID Supported - 0, 1, 5, 6, 10, 50, 60, JBOD RAID Levels - 6 x Total Bays - 6 x 2.5"/3.5" Bay - Gigabit Ethernet, 2.5 Gigabit Ethernet - HDMI - 4 USB Port(s) - 2 USB 2.0 Port(s) - Network (RJ-45) - QTS 5.1.3 - IPv4, IPv6, DHCP, CIFS/SMB, AFP, NFSv3, FTP, FTPS, SFTP, TFTP, HTTP, ... - 4 GB Flash Memory Capacity
- SKU
- TS-AI642-8G-US
- Category
- Storage Arrays & Servers
$795.14
Back ordered — ships when restocked.
Genuine QNAP Systems through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- TS-AI642-8G-US
- Category
- Storage Arrays & Servers
Overview
The next-generation TS-AI642 AI NAS is specifically designed for AI-powered video and image recognition applications. Adopting the 64-bit ARM Cortex-A76/-A55 SoC octa-core processor with up to 6 TOPS NPU (Neural network Processing Unit), the TS-AI642 not only tackles image processing and analysis tasks, but also offloads CPU workloads when running AI applications to reduce system operation power consumption. With powerful computing performance, high-capacity storage space and flexible I/O expandability, the TS-AI642 allows enterprises to easily deploy an AI NAS solution for video surveillance, image recognition, and face recognition applications.
AI computing performance of 6 TOPS NPU
With a built-in NPU (Neural network Processing Unit) processor, the TS-AI642 boosts performance for high-speed face and object recognition.
2.5GbE is a must!
2.5GbE provides higher transmission speeds with existing Cat 5e cables, making file backup/restore and media conversion smoother.
PCIe Gen 3 Expandability
Install a 2.5/5/10GbE adapter, QM2 card, or USB 3.2 Gen 2 (10Gbps) card to increase application potential.
Professional surveillance NAS solution
QVR Elite allows you to deploy up to 64 channels (2 channels are included for free).
Dual 4K HDMI? Output
Use two screens for a surveillance TV wall monitoring.
ARM hardware transcoding
Supports ARM NEON technology that accelerates video processing for a better media experience.
Highlights
- SAN/NAS Storage System offers maximum storage productivity with added dependability
- Supports up to 6 drives; for flexible storage options
- Through RAID levels (0, 1, 5, 6, 10, 50, 60, jbod), RAID provides data reliability, fault tolerance and improves overall performance
- DDR4 SDRAM memory technology for fast, easy, and convenient access and retrieval of data and information
- Perform computational tasks effectively accrediting the arm cortex a76 2.20 ghz processor
- RAID technology - data reliability, fault tolerance and improved overall performance
- Tower form factor is least expensive and highly configurable with maximum dependability
- Gigabit Ethernet is very resourceful when a large number of file transfers are required, such as when performing backups over a network
- QTS 5.1.3 OS makes you more productive and creative
Specifications
| Additional Warranty Information | The TS-AI642 is backed by a 3-year warranty at no additional cost. You can also purchase a warranty extension that extends your warranty coverage up to 5 years. |
|---|---|
| Package Contents |
|
| Product Type | SAN/NAS Storage System |
| Manufacturer Part Number | TS-AI642-8G-US |
| Protocols | IPv4, IPv6, DHCP, CIFS/SMB, AFP, NFSv3, FTP, FTPS, SFTP, TFTP, HTTP, HTTPS, Telnet, SSH, iSCSI, SNMP, SSL/TLS, FXP, WEBDAV, LDAP, DDNS, DNS, SNMPv2, SNMPv3, PPTP, L2TP, NFSv4, TLS |
| Limited Warranty | 3 Year |
| Standard Memory | 8 GB |
| Weight (Approximate) | 9.70 lb |
| Operating System | QTS 5.1.3 |
| Form Factor | Tower |
| Manufacturer | QNAP Systems |
| Product Model | TS-AI642-8G |
| Product Name | TS-AI642-8G SAN/NAS Storage System |
| Processor Speed | 2.20 GHz |
| Processor Type | Cortex A76 |
| RAID Levels | 0, 1, 5, 6, 10, 50, 60, JBOD |
| Controller Type | Serial ATA/600 |
| Brand Name | QNAP |
| Expansion Slot Type | PCI Express 3.0 x2 |
| Memory Technology | DDR4 SDRAM |
| Height | 6.5" |
| Width | 9.3" |
| Depth | 8.9" |
| Processor Core | Quad-core (4 Core) |
| Flash Memory Capacity | 4 GB |
| Processor Manufacturer | ARM |
| RAID Supported | Yes |
| Ethernet Technology | Gigabit Ethernet, 2.5 Gigabit Ethernet |
| Number of Total Expansion Bays | 6 |
| HDMI | Yes |
| Number of Network (RJ-45) Ports | 3 |
| Network (RJ-45) | Yes |
| Maximum Power Supply Wattage | 120 W |
| Total Number of USB Ports | 4 |
| Number of USB 2.0 Ports | 2 |
| Number of Hard Drives Supported | 6 |
| Number of Hard Drives Installed | 0 |
| Number of Solid State Drive Supported | 6 |
| Number of Solid State Drive Installed | 0 |
| Number of 2.5"/3.5" Bays | 6 |
| Total Number of Expansion Slots | 1 |
| 2nd Processor Manufacturer | ARM |
| 2nd Processor Type | Cortex A55 |
| 2nd Processor Speed | 1.80 GHz |
| 2nd Processor Core | Quad-core (4 Core) |
| Number of USB 3.2 Gen 2 Ports | 2 |
