Panorama Antennas LG-IN2458 Antenna
Panorama Antennas

Panorama Antennas LG-IN2458 Antenna

617 MHz to 960 MHz, 1710 MHz to 6000 MHz, 2.4 GHz, 4.9 GHz to 6.0 GHz, 1562 MHz to 1612 MHz - 9 dBi - Cellular Network, Wireless Router, GPS, Wireless Data Network - Black - Panel - Omni-directional - SMA Connector - TAA Compliant

SKU
LG-IN2458
Category
Antennas

MSRP$526.40

$392.85

Save 25%
Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Panorama Antennas through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
LG-IN2458
Category
Antennas

Overview

The LG-IN2458 is a high performance 2x2 MiMo LTE, 6x6 MiMo Dual Band WiFi and GPS/GNSS active antenna covering 617-960/1710-6000MHz.

• Low profile antenna with 9 functions in 1

• 2x2 MiMo 4G/5G LTE cellular, 6x6 MiMo Dual Band WiFi and GPS/GNSS in one housing

• Kits with extension cables available for a range of LTE routers

• Suitable for Cradlepoint COR IBR900 Series Routers

The LG-IN2458 range has been designed to provide 2x2 4G/5G MiMo performance from 617-960/1710-6000MHz in a robust low profile package. The flexible platform allows the main elements to be combined with a number of other functions including GPS/GNSS and 4x4 MiMo WiFi 2.4/5.0GHz.

The antenna is designed to be panel mounted and can be fitted on a conductive or non- conductive panel. Supplied with integrated flame retardant RG174 cables (Compliant to UNECE 118.01 and EN45545-2) and a halogen free flame retardant radome the antenna is suitable for many environments and applications.

The antenna is available with a black or white radome which meets IK10 for vandal resistance and IP69K for ingress protection.

Highlights

  • Provides optimized pattern coverage with 617 MHz to 960 MHz operating frequency range
  • Get improved signals for your cellular network with this antenna
  • Eases up the installation procedure thanks to its 360-degree horizontal pattern
  • Designed to be light in weight and easy to install

Specifications

Application/UsageCellular Network, Wireless Router, GPS, Wireless Data Network
Product TypeAntenna
CompatibilityCradlepoint COR IBR900 Series Routers
Manufacturer Part NumberLG-IN2458
Connector TypeSMA
Form FactorPanel
ManufacturerPanorama Antennas Ltd
Product ModelLG-IN2458
Product NameLG-IN2458 Antenna
Brand NamePanorama Antennas
Diameter7.09"
Height3.15"
Environmentally FriendlyYes
DirectivityOmni-directional
TAA CompliantYes
Product ColorBlack
Operating Frequency Range617 MHz to 960 MHz, 1710 MHz to 6000 MHz, 2.4 GHz, 4.9 GHz to 6.0 GHz, 1562 MHz to 1612 MHz
Antenna Gain (Isotropic)9 dBi
