Lenovo ThinkSystem SR630 V3 7D73A05KNA 1U Rack Server - 1 Xeon Silver 4509Y 2.60 GHz - 32 GB RAM - Serial ATA/600 Controller
Lenovo

Lenovo ThinkSystem SR630 V3 7D73A05KNA 1U Rack Server - 1 Xeon Silver 4509Y 2.60 GHz - 32 GB RAM - Serial ATA/600 Controller

Intel C741 Chip - 2 Processor Support - 8 TB RAM Support - TruDDR5 - 0, 1, 5, 10, JBOD RAID Levels Up to 16 MB Graphic Card - 10 x Total Bay(s) - 10 x SFF Bay(s) - Hot Swappable Bays - 1 x 750 W

SKU
7D73A05KNA
Category
Servers

Request pricing

Confirmed with stock and TAA status before any payment.

Request a quote

Genuine Lenovo through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
7D73A05KNA
Category
Servers

Overview

The Lenovo ThinkSystem SR630 V3 is an ideal 2-socket 1U rack server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. The SR630 V3 is designed to handle a wide range of workloads, such as databases, virtualization and cloud computing, virtual desktop infrastructure (VDI), infrastructure security, systems management, enterprise applications, collaboration/email, streaming media, web, and HPC.

Highlights

  • 2 processors supported for optimal performance and maximum reliability in mission-critical server environments
  • With 32 GB memory, improve system performance and reduce processing delays
  • 750 W power supply unit (PSU) fulfills system power needs, ensuring smooth operation under heavy workloads
  • Xeon Silver 2.60 GHz processor handles computing tasks effectively for better productivity
  • Rack form factor offers easy deployment and streamlined usage, enhancing operational efficiency in server environments
  • RAID enhances reliability and speed through RAID levels (0, 1, 5, 10, JBOD), balancing data protection with optimized performance
  • 5th Gen server generation delivers improved performance for faster, more efficient computing
  • With TruDDR5 memory technology, achieve faster data rates and enhanced system responsiveness for enterprise applications
  • 6 USB ports feature a refined design and safer connectivity, ensuring reliable, secure, and easy device connections every time
  • Octa-core (8 Core) processor core helps server process data quickly and reliably for maximum productivity

Specifications

Additional Warranty InformationThree-year customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD).
Package Contents
  • ThinkSystem SR630 V3 7D73A05KNA Server
  • Toolless Slide Rail Kit
Product TypeServer
Cache22.50 MB
Error CheckingECC
Input Voltage120 V AC, 230 V AC
Manufacturer Part Number7D73A05KNA
Maximum Memory Supported8 TB
Signal ProcessingRegistered (Buffered)
Limited Warranty3 Year
Standard Memory32 GB
Weight (Approximate)45.86 lb
Form FactorRack
ManufacturerLenovo Group Limited
Product Model7D73A05KNA
Product NameThinkSystem SR630 V3 7D73A05KNA Server
Processor Speed2.60 GHz
Processor TypeXeon Silver
Product LineThinkSystem
RAID Levels0, 1, 5, 10, JBOD
Security Features
  • Chassis intrusion switch
  • Power-on password
  • Administrator's password
  • Root of Trust module supporting TPM 2.0
  • Platform Firmware Resiliency (PFR)
Controller TypeSerial ATA/600
Product SeriesSR630 V3
Rack Height1U
Brand NameLenovo
Plug/Connector TypeC13
Operating System SupportedWindows Server 2019, Windows Server 2022, Red Hat Enterprise Linux 8.6, Red Hat Enterprise Linux 8.7, Red Hat Enterprise Linux 8.8, Red Hat Enterprise Linux 8.9, Red Hat Enterprise Linux 8.10, Red Hat Enterprise Linux 9.0, Red Hat Enterprise Linux 9.1, Red Hat Enterprise Linux 9.2, Red Hat Enterprise Linux 9.3, Red Hat Enterprise Linux 9.4, SUSE Linux Enterprise Server 15 SP4, SUSE Linux Enterprise Server 15 SP5, Ubuntu 22.04 LTS x64
Memory TechnologyTruDDR5
Processor Model4509Y
Height1.7"
Width17.3"
Depth30.4"
Processor CoreOcta-core (8 Core)
Environmentally FriendlyYes
Environmental CertificationChina Environmental Labeling Program (CELP), Electronic Product Environmental Assessment Tool Bronze (EPEAT Bronze), GREENGUARD
Chipset ManufacturerIntel
Chipset ModelC741
Number of Power Supplies Supported2
Number of Power Supplies Installed1
Number of Internal 2.5" Bays10
Graphics Memory Capacity16 MB
Hot Swappable Power SupplyYes
Number of Processors Supported2
Number of Processors Installed1
RAID SupportedYes
Number of Total Expansion Bays10
VGAYes
Network (RJ-45)Yes
Maximum Power Supply Wattage750 W
Remote ManagementYes
Total Number of USB Ports6
Number of USB 2.0 Ports1
Processor Generation5th Gen
Energy StarYes
Number of Occupied Memory Slots1
Hot Swappable BaysYes
Intel Optane Memory ReadyNo
Memory Clock Speed4.40 GHz
Number of SFF Bays10
Remote Management ControllerXClarity Controller (XCC) Standard
Total Number of Memory Slots32
Energy Efficiency CertificationChina Energy Conservation Program (CECP), ENERGY STAR 4.0
Energy Efficiency ComplianceEnergy-related Products Directive Lot 9 (ErP Lot 9)
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
