Lenovo S4520 480 GB Rugged Solid State Drive - 3.5" Internal - SATA (SATA/600) - Read Intensive
Lenovo

Lenovo S4520 480 GB Rugged Solid State Drive - 3.5" Internal - SATA (SATA/600) - Read Intensive

Server Device Supported - 2.8 DWPD - 2560 TB TBW - 563200 MB/s Maximum Read Transfer Rate - 256-bit AES Encryption Standard - 1 Year Warranty

SKU
4XB7A17110
Category
Hard Drives/Solid State Drives

MSRP$2,699.00

$2,513.44

Save 7%
Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Lenovo through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
4XB7A17110
Category
Hard Drives/Solid State Drives

Overview

The ThinkSystem S4520 Read Intensive SATA SSDs use 144-layer Intel 3D NAND TLC Flash Memory technology with a 6Gbps SATA interface to provide an affordable solution with industry leading performance.

Compared with the S4510 series, these new Read Intensive (Entry) drives offer improved endurance. The S4520 SSDs are optimized for read-intensive applications such as boot, web servers, lower data rate operational databases and analytics.

Highlights

  • 2.5-inch drives in multiple form form factors
  • Cost-effective Intel 3D NAND TLC Flash Memory
  • Endurance of up to 3 drive writes per day (DWPD) for 5 years, using Intel Standard Endurance Technology (SET).
  • SATA TLC solid-state drive with high read performance and consistently low latencies to fulfill client needs in the enterprise space
  • High reliability and enhanced ruggedness
  • Energy savings, with typical write power consumption as low as 2.3 W per drive
  • Absence of moving parts to reduce potential failure points in the server
  • S.M.A.R.T. support
  • Advanced Encrypting Standard (AES) 256-bit encryption
  • Full end-to-end data path protection

Specifications

Additional Warranty InformationThe S4620 SSDs carry a one-year, customer-replaceable unit (CRU) limited warranty.
Product TypeSolid State Drive
CompatibilityThinkSystem Servers: ST250 V2 (7D8G / 7D8F) SR250 V2 (7D7R / 7D7Q)
Device SupportedServer
Storage Capacity480 GB
Manufacturer Part Number4XB7A17110
Limited Warranty1 Year
Weight (Approximate)2.47 oz
Drive TypeInternal
Form Factor3.5"
ManufacturerLenovo Group Limited
Product NameThinkSystem 3.5" S4520 480GB Read Intensive SATA 6Gb SS SSD
Product SeriesS4520
Brand NameLenovo
Height0.3"
Width2.8"
Depth3.9"
Environmentally FriendlyYes
Wireless LANNo
Encryption Standard256-bit AES
Maximum Read Transfer Rate563200 MB/s
Maximum Write Transfer Rate471040 MB/s
Drive InterfaceSATA
Drive Interface StandardSATA/600
Random 4KB Read79000IOPS
Random 4KB Write30000IOPS
Endurance (DWPD)2.8
Endurance (TBW)2560 TB
Endurance TypeRead Intensive
RuggedYes
Environmental ComplianceRestriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE)
