Lenovo PM1645a 3.20 TB Solid State Drive - 2.5" Internal - SAS (12Gb/s SAS)
Lenovo

Lenovo PM1645a 3.20 TB Solid State Drive - 2.5" Internal - SAS (12Gb/s SAS)

Server Device Supported - 3 DWPD - 17520 TB TBW - 1000 MB/s Maximum Read Transfer Rate - Hot Swappable - 1 Year Warranty

SKU
4XB7A17064
Category
Hard Drives/Solid State Drives

$4,513.39

Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Lenovo through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
4XB7A17064
Category
Hard Drives/Solid State Drives

Overview

The ThinkSystem PM1645a Mainstream SAS 12Gb solid-state drives (SSDs) in capacities of up to 6.4 TB are next-generation high-performance SSDs suitable for a wide range of applications of running on ThinkSystem servers.

This product guide provides essential presales information to understand the Mainstream 12Gb SAS SSD offerings and their key features, specifications, and compatibility. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SSDs and consider their use in IT solutions.

Highlights

  • Mainstream server SSD suitable for mixed read-write-intensive workloads
  • Endurance of 3 drive-writes per day (DWPD)
  • 2.5-inch or 3.5-inch industry standard form factor with hot-swap tray
  • SAS 12 Gbps interface
  • Protect data integrity from unexpected power loss with Samsung's advanced power-loss protection architecture
  • Supports Self-Monitoring, Analysis and Reporting Technology (S.M.A.R.T)
  • End-to-end data protection
  • Support 16 Initiator with Tag Command Queuing (TCQ) Command Set with a queue-depth of up to 128 commands
  • Compliant with SCSI Specification (SAS-3 / SPL-3 / SBC-4 / SPC-4 / SAM-5)
  • RoHS Compliant

Specifications

Product TypeSolid State Drive
CompatibilityLenovo ThinkSystem Servers: ST550 (7X09/7X10) SR530 (7X07/7X08) SR550 (7X03/7X04) SR570 (7Y02/7Y03) SR590 (7X98/7X99) SR630 (7X01/7X02) SR650 (7X05/7X06) SR670 (7Y36/37/38) SR635 (7Y98/7Y99) SR655 (7Y00/7Z01) SR645 (7D2Y/7D2X) SR665 (7D2W/7D2V) SR850 (7X18/7X19) SR850P (7D2F/2D2G) SR860 (7X69/7X70) SR950 (7X11/12/13) SD530 (7X21) SN550 (7X16) SN850 (7X15)
Device SupportedServer
Storage Capacity3.20 TB
Hot SwappableYes
Manufacturer Part Number4XB7A17064
Limited Warranty1 Year
Weight (Approximate)4.94 oz
Drive TypeInternal
Form Factor2.5"
ManufacturerLenovo Group Limited
Product NameThinkSystem 2.5" PM1645a 3.2TB Mainstream SAS 12Gb Hot Swap SSD
Product SeriesPM1645a
Brand NameLenovo
Height0.6"
Width2.8"
Depth3.9"
Environmentally FriendlyYes
Wireless LANNo
Maximum Read Transfer Rate1000 MB/s
Maximum Write Transfer Rate1000 MB/s
Drive InterfaceSAS
Drive Interface Standard12Gb/s SAS
Random 4KB Read230000IOPS
Random 4KB Write140000IOPS
Endurance (DWPD)3
Endurance (TBW)17520 TB
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
