Lenovo PM983 3.84 TB Solid State Drive - 2.5" Internal - U.2 (SFF-8639) NVMe (PCI Express 3.0 x4)
Lenovo

Lenovo PM983 3.84 TB Solid State Drive - 2.5" Internal - U.2 (SFF-8639) NVMe (PCI Express 3.0 x4)

Server Device Supported - 3200 MB/s Maximum Read Transfer Rate - Hot Swappable - 1 Year Warranty - 1

SKU
4XB7A10176
Category
Hard Drives/Solid State Drives

$2,867.42

Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Lenovo through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
4XB7A10176
Category
Hard Drives/Solid State Drives

Overview

The Lenovo PM983 Entry NVMe PCIe solid-state drives (SSDs) in capacities of 1.92 TB and 3.84 TB are general-purpose yet high-performance SSDs for System x and ThinkServer systems. They are engineered for greater performance and endurance in a cost-effective design, and to support a broader set of workloads.

Did you know?

The PM983 family of SSDs are follow-ons to the PM963 drives. The PM983 drives offer improved performance, both in terms of random read/write performance (IOPS) and sequential read/write bandwidth (MB/s). Sequential write latency has also been improved.

Lenovo Entry SSDs are suitable for read-intensive and general-purpose data center workloads, however their NVMe PCIe interface means the drives also offer high performance. Overall, these SSDs provide outstanding IOPS/watt and cost/IOPS for enterprise solutions.

Highlights

  • Available in 2.5-inch (U.2) and 3.5-inch form factors
  • Low cost, read-intensive SSD from Samsung
  • Direct PCIe 3.0 x4 connection for each NVMe drive, resulting in up to 4 GBps overall throughput.
  • Advanced ECC Engine and End-to-End Data Protection
  • Samsung 32 layer V-NAND stacks the vertical NAND layers in three dimensions, solving the cell-to-cell interference that causes data corruption in planar NAND.
  • Protect data integrity from unexpected power loss with Samsung's advanced power-loss protection architecture
  • Supports Self-Monitoring, Analysis and Reporting Technology (S.M.A.R.T).

Specifications

Package Contents
  • ThinkSystem U.2 PM983 3.84TB Entry NVMe PCIe 3.0 x4 Hot Swap SSD
  • Documentation Flyer
Product TypeSolid State Drive
CompatibilityLenovo ThinkSystem Server: ST550 (7X09/7X10) SR570 (7Y02/7Y03) SR590 (7X98/7X99) SR630 (7X01/7X02) SR650 (7X05/7X06) SR850 (7X18/7X19) SR860 (7X69/7X70) SR950 (7X11/12/13) SD530 (7X21) SN550 (7X16) SN850 (7X15)
Device SupportedServer
Storage Capacity3.84 TB
Hot SwappableYes
Manufacturer Part Number4XB7A10176
Packaged Quantity1
Limited Warranty1 Year
Weight (Approximate)2.47 oz
Drive TypeInternal
Form Factor2.5"
ManufacturerLenovo Group Limited
Product NameThinkSystem U.2 PM983 3.84TB Entry NVMe PCIe 3.0 x4 Hot Swap SSD
Product SeriesPM983
Brand NameLenovo
Height0.3"
Width2.8"
Depth3.9"
Wireless LANNo
Maximum Read Transfer Rate3200 MB/s
Maximum Write Transfer Rate2000 MB/s
Drive InterfaceU.2 (SFF-8639) NVMe
Drive Interface StandardPCI Express 3.0 x4
