Legrand
Raritan PX4-5495R-E8 24-Outlets PDU
Switched with Metered-by-Outlet - NEMA L6-30P (2P3W) - 18 x IEC 60320 C13, 6 x CX, 2 x Type A USB - 208 V AC - Branch Circuit, Overload Protection - Network (RJ-45) - 9.84 ft Cord Length - 2U - Rack-mountable - Rack
- SKU
- PX4-5495R-E8
- Category
- PDUs
MSRP$2,199.00
$2,074.00
Save 6%Back ordered
Back ordered — ships when restocked.
Genuine Legrand through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- PX4-5495R-E8
- Category
- PDUs
Highlights
- With PDUs decisions for load balancing and minimizing extra cost can be managed
- Remotely monitor your equipment without any worries with Switched with Metered-by-Outlet
- IEC 60320 C13 receptacle type to ensure maximum productivity with added feasibility
- Single Phase phase PDU for reliable performance with maximum productivity
- NEMA L6-30P (2P3W) plug/connector type for reliable, productive connectivity and optimal power output
- 208 V AC input voltage for better reliance and maximum dependability
- 208 V AC output voltage for better reliance and maximum usability
Specifications
| Product Type | PDU |
|---|---|
| Input Voltage | 208 V AC |
| Manufacturer Part Number | PX4-5495R-E8 |
| Limited Warranty | 2 Year |
| Output Voltage | 208 V AC |
| Features | Multi-color LCD, Onboard Display, LED Status Indicator |
| Form Factor | Rack |
| Input Current | 30 A |
| Management |
|
| Manufacturer | Legrand Group |
| Product Model | PX4-5495R-E8 |
| Product Name | PX4-5495R-E8 24-Outlets PDU |
| Mount Type | Rack-mountable |
| Protection Type | Branch Circuit, Overload Protection |
| Product Series | PX4 |
| Rack Height | 2U |
| Brand Name | Raritan |
| Plug/Connector Type | NEMA L6-30P (2P3W) |
| Input Voltage Range | 200 V AC - 240 V AC |
| Cord Length | 9.84 ft |
| Height | 3.5" |
| Width | 17.3" |
| Depth | 11.5" |
| Input Frequency | 60 Hz |
| Phase | Single Phase |
| Receptacle Type | IEC 60320 C13, CX, Type A USB |
| Output Voltage Range | 200 V AC - 240 V AC |
| Maximum Operating Temperature | 140°F (60°C) |
| Minimum Storage Temperature | -22°F (-30°C) |
| Maximum Storage Temperature | 176°F (80°C) |
| Network (RJ-45) | Yes |
| Load Capacity (VA) | 5800 W |
| UL Listed | Yes |
| PDU Type | Switched with Metered-by-Outlet |
| Remote Outlet Switching | Yes |
| Product Color | Black |
| Color Family | Black |
| Receptacle Detail | 18 x IEC 60320 C13, 6 x CX, 2 x Type A USB |
| Product Material | Aluminum |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
