Legrand
Raritan PX4-5057-E7 36-Outlets PDU
Metered-by-Outlet, Switched - IEC 60309 (2P+E) 32A - 18 x IEC 60320 C13, 18 x CX - 230 V AC - Network (RJ-45) - Horizontal/Vertical/Toolless - Button Mount - Hot-swappable
- SKU
- PX4-5057-E7
- Category
- PDUs
MSRP$2,981.00
$2,811.56
Save 6%Back ordered
Back ordered — ships when restocked.
Genuine Legrand through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- PX4-5057-E7
- Category
- PDUs
Highlights
- A device fitted with multiple outputs for the distribution of electric power
- Easily control your equipment remotely without any hassle with Metered-by-Outlet
- IEC 60320 C13 receptacle type to ensure maximum usability and reliable power output
- Single Phase phase PDU provides optimal power output with added usability
- IEC 60309 (2P+E) 32A plug/connector type for better, dependable connectivity and desired power output
- 230 V AC input voltage for optimal performance with maximum usability
- 230 V AC output voltage for optimal performance with maximum feasibility
Specifications
| Product Type | PDU |
|---|---|
| Input Voltage | 230 V AC |
| Manufacturer Part Number | PX4-5057-E7 |
| Output Voltage | 230 V AC |
| Weight (Approximate) | 13.67 lb |
| Features | Onboard Display, Multi-color LCD |
| Form Factor | Hot-swappable |
| Input Current | 32 A |
| Manufacturer | Legrand Group |
| Product Model | PX4-5057-E7 |
| Product Name | PX4-5057-E7 36-Outlets PDU |
| Mount Type | Button Mount |
| Protection Type | Overload Protection, Circuit Breaker |
| Product Series | PX4 |
| Brand Name | Raritan |
| Plug/Connector Type | IEC 60309 (2P+E) 32A |
| Input Voltage Range | 200 V AC - 240 V AC |
| Height | 2.6" |
| Width | 2.2" |
| Depth | 70.1" |
| Phase | Single Phase |
| Receptacle Type | IEC 60320 C13, CX |
| Output Voltage Range | 200 V AC - 240 V AC |
| Network (RJ-45) | Yes |
| PDU Type | Metered-by-Outlet, Switched |
| Remote Outlet Switching | Yes |
| Mounting Orientation | Horizontal/Vertical/Toolless |
| Power Rating (VA) | 7700 VA |
| Product Color | Black Powder Coat |
| Environmental Sensors | Contact Closure, Temperature, Humidity, Air Flow, Differential Pressure, Water, Dust |
| Color Family | Black |
| Locking Receptacles | SecureLock, Locking Always-on |
| Receptacle Detail | 18 x IEC 60320 C13, 18 x CX |
