Legrand
Raritan PX3-5924V-N1 (32) NEMA 5-20R PDU
NEMA L5-20P (2P3W) - 32 x NEMA 5-20R - 120 V - Network (RJ-45)
- SKU
- PX3-5924V-N1
- Category
- PDUs
MSRP$2,581.00
$2,434.29
Save 6%Back ordered
Back ordered — ships when restocked.
Genuine Legrand through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- PX3-5924V-N1
- Category
- PDUs
Highlights
- PDU provides active metering enabling energy optimization and circuit protection
- NEMA 5-20R receptacle type to ensure maximum dependability and optimal performance
- Single Phase phase PDU for reliable performance with maximum productivity
- NEMA L5-20P (2P3W) plug/connector type for reliable, productive connectivity and optimal power output
- 120 V input voltage for better reliance and maximum dependability
- 120 V AC output voltage for optimal performance with maximum feasibility
Specifications
| Product Type | PDU |
|---|---|
| Input Voltage | 120 V |
| Manufacturer Part Number | PX3-5924V-N1 |
| Limited Warranty | 2 Year |
| Output Voltage | 120 V AC |
| Weight (Approximate) | 27.56 lb |
| Input Current | 20 A |
| Manufacturer | Legrand Group |
| Product Model | PX3-5924V-N1 |
| Product Name | PX3-5924V-N1 (32) NEMA 5-20R PDU |
| Product Series | PX3 |
| Brand Name | Raritan |
| Plug/Connector Type | NEMA L5-20P (2P3W) |
| Height | 73.1" |
| Width | 2.1" |
| Depth | 2.6" |
| Phase | Single Phase |
| Receptacle Type | NEMA 5-20R |
| Network (RJ-45) | Yes |
| Remote Outlet Switching | Yes |
| Power Rating (VA) | 1900 VA |
| Environmental Sensors | Differential Pressure, Temperature, Water, Air Flow, Humidity, Contact Closure |
| Receptacle Detail | 32 x NEMA 5-20R |
