Legrand
Raritan PX3 36-Outlets PDU
Monitored - IEC 60309 3P+N+E 6h 32A (4P5W) - 36 x IEC 60320 C13 - 415 V - Network (RJ-45) - 0U - Vertical - Rack-mountable
- SKU
- PX3-5704I2-M10V2
- Category
- PDUs
MSRP$3,227.00
$3,043.57
Save 6%Back ordered
Back ordered — ships when restocked.
Genuine Legrand through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- PX3-5704I2-M10V2
- Category
- PDUs
Highlights
- PDU improves efficiency, uptime and growth of data centers
- Before critical input source become overloaded always be warned with monitored PDUs
- IEC 60320 C13 receptacle type to ensure maximum usability and reliable power output
- Three Phase phase PDU provides optimal power output with added usability
- IEC 60309 3P+N+E 6h 32A (4P5W) plug/connector type for efficient connectivity and feasible power output
- 415 V input voltage for better reliance and maximum dependability
- 230 V AC output voltage for optimal performance with maximum feasibility
Specifications
| Product Type | PDU |
|---|---|
| Input Voltage | 415 V |
| Manufacturer Part Number | PX3-5704I2-M10V2 |
| Limited Warranty | 2 Year |
| Output Voltage | 230 V AC |
| Input Current | 32 A |
| Manufacturer | Legrand Group |
| Product Model | PX3-5704I2-M10V2 |
| Product Name | PX3 36-Outlets PDU |
| Mount Type | Rack-mountable |
| Protection Type | Overload Protection, Overcurrent Protection |
| Product Series | PX3 |
| Rack Height | 0U |
| Brand Name | Raritan |
| Plug/Connector Type | IEC 60309 3P+N+E 6h 32A (4P5W) |
| Country of Origin | Taiwan |
| Height | 70.1" |
| Width | 2.1" |
| Depth | 2.6" |
| Phase | Three Phase |
| Receptacle Type | IEC 60320 C13 |
| Environmentally Friendly | Yes |
| Network (RJ-45) | Yes |
| PDU Type | Monitored |
| Remote Outlet Switching | Yes |
| Mounting Orientation | Vertical |
| Power Rating (VA) | 17.30 kVA |
| Receptacle Detail | 36 x IEC 60320 C13 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS), Restriction of Hazardous Substances (RoHS) 2 |
