Eaton Tripp Lite Series Travel-Sized USB-C Dock and Charger - 4K HDMI, USB 3.2 Gen 1, 45W PD Charging
45 W - North America - 230 V AC, 120 V AC Input - 5 V DC, 9 V DC, 15 V DC, 20 V DC Output - 3 A - Black Box
- SKU
- U442-DOCK30
- Category
- Power Adapters
MSRP$153.77
$62.95
Save 59%Back ordered — ships when restocked.
Genuine Eaton through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- U442-DOCK30
- Category
- Power Adapters
Overview
Provides up to 45W to charge a laptop or gaming console and connects it to a 4K HDMI display.
Features | Multi-Use Travel Dock Both Charges Mobile Devices and Transmits 4K Video
This USB charger lets you quickly and safely charge your USB-C and USB-A mobile devices. Plug it into any NEMA 1-15R, NEMA 5-15R or NEMA 5-15/20R AC outlet to ensure your laptop, tablet, smartphone or handheld game console charges at its fastest possible speed. Connected devices are protected from over-current, over-voltage, over-temperature and short circuit.
Supports Maximum Power Capacity of 45W
The USB-C port supports USB Power Delivery (PD) 3.0 charging up to 5V 3A (15W), 9V 3A (27W), 15V 2.6A (39W), 15V 3A (45W) and 20V 2.25A (45W). The USB-A port provides up to 5V 0.9A (4.5W), as well as USB 3.2 Gen 1 data transfer rates up to 5 Gbps for flash drives and other USB peripherals. It can be also used to connect and charge the Joy-Con controllers of a Nintendo Switch.
Transmits 4K Video from the USB-C Host Device
Connect a 4K display to the HDMI port. The U442-DOCK30 transmits Ultra HD 4K resolutions up to 3840 x 2160 at 30 Hz from a USB-C host device that supports DisplayPort Alt Mode, such as a laptop, tablet or smartphone. It can stream 1080p high-definition video at 60 Hz from a Nintendo Switch.
Folding Plug Design Perfectly Sized for Travel
The thin-profile unit is easy to carry in your purse, suitcase, backpack or laptop bag. The NEMA 1-15P plug folds into the charger when not in use to shield it from damage and prevent it from snagging or scratching your bag's contents.
Warranty
Limited Warranty: 1 Year
About Eaton
Eaton is an intelligent power management company dedicated to improving the quality of life and protecting the environment for people everywhere. We are guided by our commitment to do business right, to operate sustainably and to help our customers manage power ─ today and well into the future. By capitalizing on the global growth trends of electrification and digitalization, we're accelerating the planet's transition to renewable energy and helping to solve the world's most urgent power management challenges.
Highlights
- Travel-sized dock/charger plugs directly into a wall outlet with no bulky transformer
- Ideal for charging laptops, tablets, smartphones and handheld game consoles
- HDMI port supports 4K @ 30 Hz from USB-C host device, including laptops
- USB-C PD charging and USB-A ports provide up to 45W simultaneous charging
- Thin-profile design fits easily inside a pocket, purse or backpack for travel use
Specifications
| Package Contents |
|
|---|---|
| Product Type | Power Adapter |
| Device Supported | USB Type C Device, Notebook, Tablet PC, Smartphone, Gaming Console, Mobile Device, USB Type A Device, Handheld Device, Chromebook, Computer, Monitor |
| Input Voltage | 230 V AC, 120 V AC |
| Localization | North America |
| Manufacturer Part Number | U442-DOCK30 |
| Packaged Quantity | Box |
| Limited Warranty | 1 Year |
| Output Voltage | 5 V DC, 9 V DC, 15 V DC, 20 V DC |
| Weight (Approximate) | 1 lb |
| Features | Overcurrent Protection, Overvoltage Protection, Over Temperature Protection, Short Circuit Protection |
| Manufacturer | Eaton Corporation |
| Product Model | U442-DOCK30 |
| Product Name | U442-DOCK30 AC Adapter |
| Brand Name | Tripp Lite series |
| Country of Origin | Vietnam |
| Height | 2.4" |
| Width | 1.2" |
| Depth | 2.3" |
| Universal Adapter | Yes |
| Maximum Output Current | 3 A |
| Maximum Output Power | 45 W |
| USB | Yes |
| Number of USB Ports | 1 |
| USB Type-C | Yes |
| Number of USB Type-C Ports | 1 |
| Product Color | Black |
| USB Power Delivery | 1 x Type-C 45W |
| Color Family | Black |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE), Restriction of Hazardous Substances (RoHS) |
