Tripp Lite by Eaton DisplayPort KVM Cable Kit 3 in 1 - 4K DisplayPort USB 3.5 mm Audio (3xM/3xM) 4:4:4 6 ft. (1.83 m) Black
5.91 ft KVM Cable for KVM Switch, Computer - First End: 1 x Mini-phone Male Audio, First End: 1 x DisplayPort Male Digital Audio/Video, First End: 1 x Type A Male USB - Second End: 1 x Mini-phone Male Audio, Second End: 1 x DisplayPort Male Digital Audio/Video, Second End: 1 x Type B Male USB - 60 MB/s - Supports up to 3840 x 2160 - Gold Plated Contact - Black
- SKU
- P783-006
- Category
- Connector Cables
MSRP$87.21
$37.93
Save 57%In stock: 951
Genuine Eaton through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- P783-006
- Category
- Connector Cables
Overview
6 ft. 3-in-1 Cable Connects Your DisplayPort Computer to a Tripp Lite NIAP KVM Switch
This cable features DisplayPort, USB A/B and 3.5 mm audio connectors on both ends for connecting your computer to a KVM switch. Designed specifically for the Tripp Lite B002-DP1A4 NIAP KVM, the six-foot cable supports DisplayPort video resolutions up to 3840 x 2160 (4K x 2K) at 60 Hz with true 4:4:4 chroma subsampling. It's compatible with HDCP 2.2, DisplayPort 1.2 and USB 2.0 (480 Mbps) standards. By combining three different cables into one convenient cord, you cut down on unnecessary clutter and save money.
More from the Manufacturer
3-in-1 Cable Kit Connects Your DisplayPort Computer to a Tripp Lite NIAP KVM Switch
Featuring DisplayPort, USB and 3.5 mm audio connectors on both ends, Tripp Lite’s P783-006 connects your DisplayPort computer to a KVM switch in one fell swoop, without requiring different cables. Recommended for Tripp Lite’s B002-DPIA4 NIAP KVM switch, this 6 ft. cable cuts down on clutter and saves money by eliminating the need to purchase additional cables.
Typical Applications
Connect a headless—i.e., CLI (command line interface)—computer, server, switch or router to a Tripp Lite KVM switch
Upgrade or replace worn or lost cables
Extend the distance between a KVM switch and computer to 6 ft.
Supports Ultra-High Definition Resolutions and Meets the Latest Color Standards
This top-of-the-line cable kit delivers UHD picture quality at resolutions up to 3840 x 2160 (4K x 2K) @ 60 Hz. It supports true 4:4:4 chroma subsampling, reducing data rate and file size, and meets HDCP 2.2, DisplayPort 1.2 and USB 2.0 standards (with speeds up to 480 Mbps).
Delivers true 4K resolutions and provides outstanding color quality
Meets or exceeds the latest industry standards
Supports data transfer speeds up to 480 Mbps
Installs Quickly and Easily with No Software Required
With no software required for installation and all cables combined into one kit, the P783-006 is completely plug and play. It installs easily and immediately, reducing the skill level required for connecting your computer and the labor time involved in your installation.
Can be installed in little time by almost anyone
Cuts down on costs involved in installation
Warranty
Limited Warranty: Lifetime
About Eaton
Eaton is an intelligent power management company dedicated to improving the quality of life and protecting the environment for people everywhere. We are guided by our commitment to do business right, to operate sustainably and to help our customers manage power ─ today and well into the future. By capitalizing on the global growth trends of electrification and digitalization, we're accelerating the planet's transition to renewable energy and helping to solve the world's most urgent power management challenges.
Highlights
- Cuts cable clutter and saves money by combining 3 essential KVM cables into one
- Delivers UHD picture quality at resolutions up to 3840 x 2160 (4K x 2K) @ 60 Hz
- Supports true 4:4:4 chroma subsampling to meet latest color standards
- Transfers data at reliable USB 2.0 speeds up to 480 Mbps
- Plug-and-play operation with no software required for easy, immediate installation
- This product is covered by a Lifetime Limited Warranty
Specifications
| Cable Length | 6 ft |
|---|---|
| Product Type | KVM Cable |
| Compatibility | Tripp Lite B002-DP1A4 NIAP KVM Switch |
| Data Transfer Rate | 480 Mbit/s |
| Device Supported | KVM Switch, Computer |
| Manufacturer Part Number | P783-006 |
| Limited Warranty | Lifetime |
| Features | HDCP 2.2 |
| Manufacturer | Eaton Corporation |
| Product Model | P783-006 |
| Product Name | KVM Cable |
| Brand Name | Tripp Lite series |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Connector Type on First End | Mini-phone Audio - Male, DisplayPort 1.2 Digital Audio/Video - Male, USB 2.0 Type A - Male |
| Connector Type on Second End | Mini-phone Audio - Male, DisplayPort 1.2 Digital Audio/Video - Male, USB 2.0 Type B - Male |
| Supported Resolution | 3840 x 2160 |
| Contact Plating | Gold |
| Product Color | Black |
| Color Family | Black |
| Connector on First End Details | 1 x Mini-phone Audio - Male, 1 x DisplayPort 1.2 Digital Audio/Video - Male, 1 x USB 2.0 Type A - Male |
| Connector on Second End Details | 1 x Mini-phone Audio - Male, 1 x DisplayPort 1.2 Digital Audio/Video - Male, 1 x USB 2.0 Type B - Male |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
