Tripp Lite by Eaton MTP/MPO Multimode Base-8 Trunk Cable, 24-Strand, 40GB/100GB, 40/100GBASE-SR4, OM4 Plenum-Rated (3xF/3xF), Push/Pull Tab, Magenta, 38 m (124 ft.)
Fiber Optic for Network Device - 12.50 GB/s - 124.67 ft - 3 x MTP/MPO Female Network - 3 x MTP/MPO Female Network - 50/125 µm - Magenta
- SKU
- N858-38M-3X8-MG
- Category
- Connector Cables
Request pricing
Confirmed with stock and TAA status before any payment.
Genuine Eaton through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- N858-38M-3X8-MG
- Category
- Connector Cables
Overview
The 38-meter (124-foot) N858-38M-3X8-MG MTP/MPO Multimode Base-8 Trunk Cable supports 40/100 Gb Ethernet speeds and is designed for high-density connections between network equipment in telecommunication rooms and data centers.
With three female MTP/MPO connectors on each end, this OM4-rated multimode fiber optic cable is recommended for high-density fiber patching between data center MDFs (main distribution frames) and IDFs (intermediate distribution frames). It's colored magenta for instant identification as an OM4 cable. Push/pull tab connectors are easily accessible in high-density data center applications and make the cable easy to install and remove with one hand.
The 8-fiber MTP/MPO connectors are about the same size as SC connectors, but are 12 times denser, freeing up rack space for other cables. Optimized for QSFP+ 40GBASE-SR4 and QSFP28 100GBASE-SR4 networks, this cable is tested for low insertion loss and back reflection on every connector and attenuation loss that meets or exceeds current standards. The 5.6-millimeter ruggedized plenum-rated jacket and bend-insensitive fiber are perfect for connecting high-speed network components in ceilings, walls and ducts.
Features
OM4-Rated for 40/100 Gb Ethernet Applications
• Designed to extend high-density connections between network equipment in telecom rooms and data centers
• Recommended for patching between data center MDFs and IDFs
• Optimized for QSFP+ 40GBASE-SR4 and QSFP28 100GBASE-SR4 networks
• Magenta-colored for identification as an OM4 cable
MTP/MPO Connectors with Push/Pull Tabs
• 8-fiber female connectors 12 times denser than SC connectors
• Push/pull tab connectors easy to install and remove with one hand
• 100% tested for low insertion loss and back reflection
Error-Free Signal Transfer
• 50/125 duplex glass fiber construction
• Plenum-rated jacket and bend-insensitive fiber perfect for ceilings, walls and ducts
Warranty
Limited Warranty: Lifetime
About Eaton
Eaton is an intelligent power management company dedicated to improving the quality of life and protecting the environment for people everywhere. We are guided by our commitment to do business right, to operate sustainably and to help our customers manage power ─ today and well into the future. By capitalizing on the global growth trends of electrification and digitalization, we're accelerating the planet's transition to renewable energy and helping to solve the world's most urgent power management challenges.
Highlights
- Offers dependable network connectivity for stable performance, supporting uninterrupted operations and consistent data flow across connected systems
- Features fiber optic cable type to deliver high-bandwidth data transmission with minimal signal loss, ensuring optimal performance in network setups
- Features MTP/MPO Network - Female connector, permitting you to establish a secure link with a network device for dependable functionality
Specifications
| Cable Length | 124.70 ft |
|---|---|
| Product Type | Network Cable |
| Data Transfer Rate | 100 Gbit/s |
| Device Supported | Network Device |
| Manufacturer Part Number | N858-38M-3X8-MG |
| Limited Warranty | Lifetime |
| Manufacturer | Eaton Corporation |
| Product Model | N858-38M-3X8-MG |
| Product Name | N858-38M-3X8-MG MTP/MPO Multimode Base-8 Trunk Cable, Magenta, 38 m |
| Brand Name | Tripp Lite series |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Cable Type | Fiber Optic |
| Connector Type on First End | MTP/MPO Network - Female |
| Connector Type on Second End | MTP/MPO Network - Female |
| Fiber Optic Mode | Multi-mode |
| Product Color | Magenta |
| Color Family | Pink |
| Connector on First End Details | 3 x MTP/MPO Network - Female |
| Connector on Second End Details | 3 x MTP/MPO Network - Female |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Fiber Optic Cable Core/Cladding Specification | 50/125 µm |
