Eaton Metered Input Rack PDU 5.76 kW max 200-240V 24A 1U Single-Phase PDU
Eaton

Eaton Metered Input Rack PDU 5.76 kW max 200-240V 24A 1U Single-Phase PDU

NEMA L6-30P - 8 x IEC 60320 C13, 4 x IEC 60320 C19 - 230 V AC - 5760 W - Network (RJ-45) - 1U - Horizontal

SKU
EMIT04-10
Category
PDUs

Request pricing

Confirmed with stock and TAA status before any payment.

Request a quote

Genuine Eaton through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
EMIT04-10
Category
PDUs

Overview

Eaton Metered Input ePDUs provide remote monitoring of the current draw of individual sections via network communication. This capability, combined with state-of-the-art software allows you to aggregate the information from many ePDUs in one location. A local display is also available for phase balancing and for easy start-up and provisioning of servers. New ePDU G3 Metered Input models feature best-in-class technologies, including ±1% billing grade accuracy, an advanced LCD pixel display, a hot-swap meter and the ability to daisy chain four ePDUs to share the same network connection and IP address.

Warranty

Limited Warranty: 3 Year

About Eaton

We're dedicated to improving people's lives and the environment with power management technologies that are more reliable, efficient, safe and sustainable. Every day, all around the world, people depend on technology, transportation, energy and infrastructure to live and work. With rapid growth in electrification, an energy transition driven by climate change and explosive growth in connectivity, we’re well positioned to solve the world’s toughest electrical and mechanical power management challenges. Because that’s what really matters. And we’re here to make sure it works. ​

Highlights

  • A device fitted with multiple outputs for the distribution of electric power
  • IEC 60320 C13 receptacle type to ensure maximum usability and reliable power output
  • NEMA L6-30P plug/connector type for efficient connectivity and feasible power output
  • 230 V AC input voltage for maximum feasibility and added productivity
  • 230 V AC output voltage for maximum dependability and added productivity

Specifications

Package Contents
  • ePDU Metered EMIT04-10 12-Outlet PDU
  • SPK021 - INSTALLATION
  • SPK013 - NETWORK
Product TypePDU
Input Voltage230 V AC
Manufacturer Part NumberEMIT04-10
Limited Warranty3 Year
Output Voltage230 V AC
Input Current24 A
ManufacturerEaton Corporation
Product ModelEMIT04-10
Product NameePDU Metered EMIT04-10 12-Outlet PDU
Product LineePDU
Product SeriesMetered
Rack Height1U
Brand NameEaton
Plug/Connector TypeNEMA L6-30P
Country of OriginUnited States
Height19"
Width1.7"
Depth8"
Receptacle TypeIEC 60320 C13, IEC 60320 C19
Network (RJ-45)Yes
Mounting OrientationHorizontal
Power Rating (Watt)5760 W
Receptacle Detail8 x IEC 60320 C13, 4 x IEC 60320 C19
Plug/Connector Detail1 x NEMA L6-30P
