Eaton fuse disconnect rack PDU, 0U, Hardwired input, 17.3 kW max, 230/400V, 24A, Hardwired, Three-phase, Outlets: (48) C13 Outlet grip, (12) C19 Outlet grip
Eaton

Eaton fuse disconnect rack PDU, 0U, Hardwired input, 17.3 kW max, 230/400V, 24A, Hardwired, Three-phase, Outlets: (48) C13 Outlet grip, (12) C19 Outlet grip

Hardwired - 48 x IEC 60320 C13, 12 x IEC 60320 C19 - 17.30 kW - Network (RJ-45) - 0U - Vertical - Rack-mountable

SKU
EMI355-HW
Category
PDUs

MSRP$1,745.00

$1,419.29

Save 19%
Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Eaton through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
EMI355-HW
Category
PDUs

Overview

Eaton Metered Input ePDUs provide remote monitoring of the current draw of individual sections via network communication. This capability, combined with state-of-the-art software allows you to aggregate the information from many ePDUs in one location. A local display is also available for phase balancing and for easy start-up and provisioning of servers. New ePDU G3Metered Input models feature best-in-class technologies, including ±1% billing grade accuracy, an advanced LCD pixel display, a hot-swap meter and the ability to daisy chain four ePDUs to share the same network connection and IP address.

Warranty

Limited Warranty: 3 Year

About Eaton

We're dedicated to improving people's lives and the environment with power management technologies that are more reliable, efficient, safe and sustainable. Every day, all around the world, people depend on technology, transportation, energy and infrastructure to live and work. With rapid growth in electrification, an energy transition driven by climate change and explosive growth in connectivity, we’re well positioned to solve the world’s toughest electrical and mechanical power management challenges. Because that’s what really matters. And we’re here to make sure it works. ​

Highlights

  • PDU is reliable for power protection and management solutions
  • IEC 60320 C13 receptacle type to ensure maximum productivity with added feasibility
  • Hardwired plug/connector type for efficient connectivity and feasible power output

Specifications

Product TypePDU
Manufacturer Part NumberEMI355-HW
Limited Warranty3 Year
Input Current24 A
ManufacturerEaton Corporation
Product ModelEMI355-HW
Product NameMetered EMI355-HW 60-Outlet PDU
Mount TypeRack-mountable
Product LineMetered
Rack Height0U
Brand NameEaton
Plug/Connector TypeHardwired
Input Voltage Range230 V AC - 400 V AC
Country of OriginUnited States
Height63.1"
Width4.1"
Depth2.1"
Receptacle TypeIEC 60320 C13, IEC 60320 C19
Network (RJ-45)Yes
Mounting OrientationVertical
Power Rating (Watt)17.30 kW
Receptacle Detail48 x IEC 60320 C13, 12 x IEC 60320 C19
