Eaton Basic rack PDU, 0U, 309-460P9 input, 17.3 kW max, 200-240V, 45A, 6 ft cord, Three-phase, Outlets: (21) C13 Outlet grip, (12) C19 Outlet grip

IEC 60309 460P9 - 21 x IEC 60320 C13, 12 x IEC 60320 C19 - 230 V AC - 17.30 kW - 6 ft Cord Length - 38U - Rack-mountable

SKU: EBA307-06
Category: PDUs

MSRP$1,575.00

$1,281.02

Save 19%

Back ordered

Back ordered — ships when restocked.

Genuine Eaton through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU: EBA307-06
Category: PDUs

Overview

Eaton G3 Basic ePDUs provide reliable power distribution for IT and data center applciations. Desgined to operate at high temperatures for high reliability and made from light-weight aluminum for ease of installation.

• IEC outlet grip plug retention secures plugs in place using standard cables

• High operating temperature (140F / 60C) for containment or hot network closet environments

• Color coded outlet sections simplify load balancing

• Low profile form factor reduces interference into the rail space

• Ease of installation using pre-installed buttons for tool-less mounting

• Designed for mission critical IT or data center applications

Warranty

Limited Warranty: 3 Year

About Eaton

We're dedicated to improving people's lives and the environment with power management technologies that are more reliable, efficient, safe and sustainable. Every day, all around the world, people depend on technology, transportation, energy and infrastructure to live and work. With rapid growth in electrification, an energy transition driven by climate change and explosive growth in connectivity, we’re well positioned to solve the world’s toughest electrical and mechanical power management challenges. Because that’s what really matters. And we’re here to make sure it works.

Highlights

ePDU G3 models feature IEC outlet grip, color-coded outlet sections, low-profile form factor and a high operating temperature for best-in-class power management
Available in horizontal and vertical solutions for a wide range of key applications
Clearly labeled circuits simplify load balancing
Cost effective solutions to meet your Basic needs
Ranges from 15A to 30A up to 208V to offer a variety of plug and outlet configurations
UL 60950 compliant to meet industry requirements

Specifications

Product Type	PDU
Input Voltage	230 V AC
Manufacturer Part Number	EBA307-06
Limited Warranty	3 Year
Weight (Approximate)	21.90 lb
Input Current	45 A
Manufacturer	Eaton Corporation
Product Name	ePDU 33-Outlets PDU
Mount Type	Rack-mountable
Product Line	ePDU
Rack Height	38U
Brand Name	Eaton
Plug/Connector Type	IEC 60309 460P9
Country of Origin	United States
Cord Length	6 ft
Height	66.5"
Width	2.1"
Depth	2.1"
Receptacle Type	IEC 60320 C13, IEC 60320 C19
Power Rating (Watt)	17.30 kW
Receptacle Detail	21 x IEC 60320 C13, 12 x IEC 60320 C19
