Datalogic PowerScan PM9600 Barcode Scanner
Wireless Connectivity - 1D, 2D - Imager - Omni-directional - , Radio Frequency - Ethernet - Yellow, Black - IP65, IP67 - Manufacturing, Warehouse, Logistics, Picking, Inventory, Asset Tracking
- SKU
- PM9600-HP433RBK30
- Category
- Barcode Scanners
Request pricing
Confirmed with stock and TAA status before any payment.
Genuine Datalogic S.p.A through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- PM9600-HP433RBK30
- Category
- Barcode Scanners
Overview
ULTRA-RUGGED WITH NEW BALANCED ERGONOMICS!
The PowerScan family of bar code readers are the ultimate industrial handheld scanners designed and constructed to withstand the toughest environmental conditions. The PowerScan 9600 imagers have an ultrarugged design, an ergonomic shape with well-balanced weight to reduce operator stress during daily activities.
MOBILITY ENHANCES PRODUCTIVITY
The PowerScan PM9600 cordless model further enhances the operator efficiency and safety with Datalogic's STAR Cordless System?. Bidirectional radio communication and display allow users to receive immediate feedback avoiding any risk of mistakes. The PowerScan PBT9600 cordless model is enriched with Bluetooth® 5.0 that can be paired to any device supporting Bluetooth connections, or to the Bluetooth base station. The BC9600 base/charger has a modular design and is available with multiple interface plug-ins for standard and industrial communication, such as RS-232, USB, Standard Ethernet and Industrial Ethernet protocols.
WIRELESS CHARGING
The PowerScan 9600 scanner features Datalogic's Wireless Charging System. Based on inductive-charging technology, Datalogic's Wireless Charging System eliminates battery contacts and pins that often get dirty, bent, or broken over time - and this removes a key point of failure for devices used in industrial and retail functions.
THREE OPTIC OPTIONS TO FULFILL ANY CUSTOMER NEED
The PowerScan 9600 area imagers are available in three different optics, to satisfy any customer need. The Standard Range optic is ideal for most of the applications requiring barcode reading at intuitive distance; the High Performance optic adds the capability to decode high density barcodes together with an increased depth of field on standard 1D/2D codes; the Document Capture model is thought for Wide Angle code reading and Document Capture applications.
Highlights
- Allows productive and precise reading of 1D barcodes
- Regardless of angle orientation, the imager makes it easy to scan 1D and 2D barcodes
- Increases productivity by giving the opportunity to wander, without the tangle of cables
Specifications
| Application/Usage | Manufacturing, Warehouse, Logistics, Picking, Inventory, Asset Tracking |
|---|---|
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Host Interface | Ethernet |
| Product Type | Barcode Scanner Kit |
| Display Screen | Yes |
| Manufacturer Part Number | PM9600-HP433RBK30 |
| Number of Keys | 4 |
| Weight (Approximate) | 15.70 oz |
| Connectivity Technology | Wireless |
| Form Factor | Handheld |
| Length | 5.5" |
| Manufacturer | Datalogic S.p.A |
| Product Model | PM9600 |
| Product Name | PowerScan PM9600 Barcode Scanner |
| Product Line | PowerScan |
| Brand Name | Datalogic |
| Height | 7.8" |
| Width | 3.1" |
| Battery Capacity | 3350 mAh |
| Scanner Range | High Density |
| Scan Pattern | Omni-directional |
| Maximum Battery Recharge Time | 2.50 Hour |
| Image Sensor Type | Imager |
| Radio Frequency | Yes |
| Illumination Type | LED |
| Storage Temperature | -40°F (-40°C) to 158°F (70°C) |
| Product Color | Yellow, Black |
| Color Family | Dual Color |
| Illumination Color | White |
| Ingress Protection (IP) Rating | IP65, IP67 |
| Rugged | Yes |
| Scanning Capability | 1D, 2D |
| Field of View (Horizontal) | 38° |
| Field of View (Vertical) | 24° |
| Reading Angle (Skew) | 52° |
| Reading Angle (Pitch) | 52° |
| Reading Angle (Roll) | 360° |
| Maximum Ambient Light | 100000 lux |
| Minimum Print Contrast | 15% |
| Maximum Element Resolution (DataMatrix) | 10 mil |
| Maximum Element Resolution (PDF417) | 10 mil |
| Operating Temperature | -4°F (-20°C) to 122°F (50°C) |
| Image Sensor Resolution | 1280 x 800 |
| Humidity (Non-condensing) | 95% |
