AddOn MSA and TAA 25GBase-DWDM SFP28 Transceiver C-Band 100GHz (SMF, 1538.19nm, 10km, LC, DOM, -40 to 85C)
AddOn

AddOn MSA and TAA 25GBase-DWDM SFP28 Transceiver C-Band 100GHz (SMF, 1538.19nm, 10km, LC, DOM, -40 to 85C)

For Data Networking, Optical Network - LC 25GBase-DWDM Network - Optical Fiber - 1538.19 nm Wavelength - Single-mode - 25 Gigabit Ethernet - 25GBase-DWDM - 25 Gbit/s - 10 km Maximum Distance - Hot-pluggable - 1 - TAA Compliant

SKU
SFP-25GBDW49-10-I-AO
Category
Modules

MSRP$2,600.00

$1,480.27

Save 43%
Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine AddOn through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
SFP-25GBDW49-10-I-AO
Category
Modules

Overview

This MSA compliant SFP28 transceiver provides 25GBase-DWDM throughput up to 10km over single-mode fiber (SMF) using a wavelength of 1538.19nm via an LC connector. It is capable of withstanding rugged environments and can operate at temperatures between -40 and 85C. All of our transceivers are built to comply with Multi-Source Agreement (MSA) standards and are uniquely serialized and tested for data-traffic and application to ensure seamless network integration. Additional product features include Digital Optical Monitoring (DOM) support which allows access to real-time operating parameters. This transceiver is Trade Agreements Act (TAA) compliant. We stand behind the quality of our products and proudly offer a limited lifetime warranty.

Highlights

  • Hot-pluggable SFP28 footprint
  • Data rate from 24.33Gbps to 25.78Gbps
  • Compliant to SFF-8431 and SFF-8472
  • Up to 10km reach with FEC
  • 100GHz ITU, C Band DWDM Cooled EML laser
  • PIN receiver
  • Full Duplex LC connector
  • Single 3.3V power supply
  • Built-in digital diagnostic functions
  • Power dissipation: <2.0W

Specifications

Application/UsageData Networking, Optical Network
Product TypeSFP28
CompatibilityMSA Compliant
Manufacturer Part NumberSFP-25GBDW49-10-I-AO
Maximum Distance Supported10 km
Packaged Quantity1
Interfaces/Ports DetailsLC 25GBase-DWDM Network
Limited WarrantyLifetime
Weight (Approximate)0.20 lb
Connector TypeLC
FeaturesDigital Optical Monitoring (DOM)
Form FactorHot-pluggable
ManufacturerAddOn
Product NameSFP28 Module
Network Technology25GBase-DWDM
Brand NameAddOn
Country of OriginUnited States/United Kingdom
Height0.4"
Width1.2"
Depth2.6"
Environmentally FriendlyYes
Maximum Data Transfer Rate25 Gbit/s
Ethernet Technology25 Gigabit Ethernet
Media Type SupportedOptical Fiber
Fiber Mode SupportedSingle-mode
Total Number of Ports1
TAA CompliantYes
Environmental ComplianceWaste Electrical and Electronic Equipment Directive (WEEE), Restriction of Hazardous Substances (RoHS), Restriction of Hazardous Substances (RoHS) 2
Fiber Optic Cable Wavelength1538.19 nm
