AddOn MSA and TAA 25GBase-DWDM SFP28 Transceiver C-Band 100GHz (SMF, 1560.61nm, 10km, LC, DOM, -40 to 85C)
For Data Networking, Optical Network - LC 25GBase-DWDM Network - Optical Fiber - 1560.61 nm Wavelength - Single-mode - 25 Gigabit Ethernet - 25GBase-DWDM - 25 Gbit/s - 10 km Maximum Distance - Hot-pluggable - 1 - TAA Compliant
- SKU
- SFP-25GBDW21-10-I-AO
- Category
- Modules
MSRP$2,600.00
$1,480.27
Save 43%Back ordered — ships when restocked.
Genuine AddOn through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- SFP-25GBDW21-10-I-AO
- Category
- Modules
Overview
This MSA compliant SFP28 transceiver provides 25GBase-DWDM throughput up to 10km over single-mode fiber (SMF) using a wavelength of 1560.61nm via an LC connector. It is capable of withstanding rugged environments and can operate at temperatures between -40 and 85C. All of our transceivers are built to comply with Multi-Source Agreement (MSA) standards and are uniquely serialized and tested for data-traffic and application to ensure seamless network integration. Additional product features include Digital Optical Monitoring (DOM) support which allows access to real-time operating parameters. This transceiver is Trade Agreements Act (TAA) compliant. We stand behind the quality of our products and proudly offer a limited lifetime warranty.
Highlights
- Hot-pluggable SFP28 footprint
- Data rate from 24.33Gbps to 25.78Gbps
- Compliant to SFF-8431 and SFF-8472
- Up to 10km reach with FEC
- 100GHz ITU, C Band DWDM Cooled EML laser
- PIN receiver
- Full Duplex LC connector
- Single 3.3V power supply
- Built-in digital diagnostic functions
- Power dissipation: <2.0W
Specifications
| Application/Usage | Data Networking, Optical Network |
|---|---|
| Product Type | SFP28 |
| Compatibility | MSA Compliant |
| Manufacturer Part Number | SFP-25GBDW21-10-I-AO |
| Maximum Distance Supported | 10 km |
| Packaged Quantity | 1 |
| Interfaces/Ports Details | LC 25GBase-DWDM Network |
| Limited Warranty | Lifetime |
| Weight (Approximate) | 0.20 lb |
| Connector Type | LC |
| Features | Digital Optical Monitoring (DOM) |
| Form Factor | Hot-pluggable |
| Manufacturer | AddOn |
| Product Name | SFP28 Module |
| Network Technology | 25GBase-DWDM |
| Brand Name | AddOn |
| Country of Origin | United States/United Kingdom |
| Height | 0.4" |
| Width | 1.2" |
| Depth | 2.6" |
| Environmentally Friendly | Yes |
| Maximum Data Transfer Rate | 25 Gbit/s |
| Ethernet Technology | 25 Gigabit Ethernet |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Single-mode |
| Total Number of Ports | 1 |
| TAA Compliant | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE), Restriction of Hazardous Substances (RoHS), Restriction of Hazardous Substances (RoHS) 2 |
| Fiber Optic Cable Wavelength | 1560.61 nm |
