AddOn MSA and TAA Compliant 25GBase-CU QSFP28 to 1xSFP28 Direct Attach Cable (Passive Twinax, 50cm)
AddOn

AddOn MSA and TAA Compliant 25GBase-CU QSFP28 to 1xSFP28 Direct Attach Cable (Passive Twinax, 50cm)

1.64 ft Twinaxial Network Cable for Network Device, Transceiver - First End: 1 x QSFP28 Network - Second End: 1 x SFP28 Network - 25 Gbit/s - 30 AWG - Black - 1.0 - TAA Compliant

SKU
QSFP28-1SFP28-PDAC0-5M-AO
Category
Connector Cables

MSRP$240.00

$136.64

Save 43%
Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine AddOn through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
QSFP28-1SFP28-PDAC0-5M-AO
Category
Connector Cables

Overview

This is an MSA compliant 25GBase-CU QSFP28 to 1xSFP28 direct attach cable that operates over passive copper with a maximum reach of 0.5m (1.6ft). It has been programmed, uniquely serialized, and data-traffic and application tested to ensure it is 100% compliant and functional. This direct attach cable is TAA (Trade Agreements Act) compliant, and is built to comply with MSA (Multi-Source Agreement) standards. We stand behind the quality of our products and proudly offer a limited lifetime warranty.

Highlights

  • QSFP28 End: Compliant with QSFP28 MSA specifications
  • SFP28 End: Compliant with SFP28 MSA specifications
  • 1 independent duplex channels operating at 25Gbps
  • AC coupled inputs and outputs
  • 100 Ohm differential impedance
  • 26AWG to 30AWG Wire Gauge
  • All-metal housing for superior EMI performance
  • Single power supply 3.3V, low power consumption
  • Operating Temperature: 0°C to 70°C
  • ROHS Compliant

Specifications

Cable Length1.64 ft
Product TypeNetwork Cable
Data Transfer Rate25 Gbit/s
Device SupportedNetwork Device, Transceiver
Manufacturer Part NumberQSFP28-1SFP28-PDAC0-5M-AO
Packaged Quantity1.0
Limited WarrantyLifetime
FeaturesPassive, EMI Protection, Lead-free, Bendable
ManufacturerAddOn
Product NameTwinaxial Network Cable
Brand NameAddOn
Country of OriginUnited States/United Kingdom
Environmentally FriendlyYes
Cable TypeTwinaxial
Connector Type on First EndQSFP28 Network
Connector Type on Second EndSFP28 Network
American Wire Gauge30 AWG
TAA CompliantYes
Product ColorBlack
Color FamilyBlack
Connector on First End Details1 x QSFP28 Network
Connector on Second End Details1 x SFP28 Network
Product MaterialCopper
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
