AddOn Cisco® Compatible TAA 400GBase-BX SR4.2 PAM4 QSFP-DD Transceiver (MMF, 850nm to 902nm, 100m, MPO-12, DOM, CMIS 4.0)
For Data Networking, Optical Network - 1 x MPO-12 400GBase-SR4.2-BX Network - Optical Fiber - 850 nm, 902 nm Wavelength - Multi-mode - 400 Gigabit Ethernet - 400GBase-SR4.2-BX - 400 Gbit/s - 0.10 km Maximum Distance - Hot-pluggable - 1 - TAA Compliant
- SKU
- QDD4-400GB-SR4-BD-C-AO
- Category
- Modules
MSRP$4,855.00
$2,764.12
Save 43%Back ordered — ships when restocked.
Genuine AddOn through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- QDD4-400GB-SR4-BD-C-AO
- Category
- Modules
Overview
This Cisco compatible QSFP-DD transceiver provides 400GBase-BX SR4.2 throughput up to 100m over multi-mode fiber (MMF) PAM4 using a wavelength of 850nm to 902nm via an MPO-12 connector. This bidirectional unit must be used with another transceiver or network appliance of complementing wavelengths. It can operate at temperatures between 0 and 70C. Our transceiver is built to meet or exceed OEM specifications and is guaranteed to be 100% compatible with Cisco. It has been programmed, uniquely serialized, and tested for data-traffic and application to ensure that it will initialize and perform identically. All of our transceivers comply with Multi-Source Agreement (MSA) standards to provide seamless network integration. Additional product features include Digital Optical Monitoring (DOM) support which allows access to real-time operating parameters. We stand behind the quality of our products and proudly offer a limited lifetime warranty.
Highlights
- QSFP-DDprovides enhanced usability with optimal efficiency and convenience
- 400GBase-SR4.2-BX network technology for reliable connectivity with maximum productivity
- 400 Gigabit Ethernet Ethernet technology for a reliable, convenient way of communication and connectivity
- Supports optical fiber cable for durable performance, minimal signal loss, and fast data transfers to greater distances
- With its thicker diameter to carry the light of multiple wavelengths, multi-mode fiber optic cable supports the high bandwidth to carry more information with greater fidelity
- Hot-pluggable form factor for your convenience and simplicity of usage
- QSFP-DDwithdata networkingapplication/usage ensures maximum dependability and convenience
Specifications
| Application/Usage | Data Networking, Optical Network |
|---|---|
| Product Type | QSFP-DD |
| Compatibility | MSA Compliant |
| Manufacturer Part Number | QDD4-400GB-SR4-BD-C-AO |
| Maximum Distance Supported | 0.10 km |
| Packaged Quantity | 1 |
| Interfaces/Ports Details | 1 x MPO-12 400GBase-SR4.2-BX Network |
| Limited Warranty | Lifetime |
| Weight (Approximate) | 0.11 lb |
| Connector Type | MPO-12 |
| Features | Digital Optical Monitoring (DOM) |
| Form Factor | Hot-pluggable |
| Manufacturer | AddOn |
| Product Name | Cisco QSFP-DD Module |
| Network Technology | 400GBase-SR4.2-BX |
| Brand Name | AddOn |
| Country of Origin | United States/United Kingdom |
| Height | 0.4" |
| Width | 0.8" |
| Depth | 4.9" |
| Environmentally Friendly | Yes |
| Maximum Data Transfer Rate | 400 Gbit/s |
| Ethernet Technology | 400 Gigabit Ethernet |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Multi-mode |
| Total Number of Ports | 1 |
| TAA Compliant | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Fiber Optic Cable Wavelength | 850 nm, 902 nm |
