AddOn Fiber Optic Network Cable
147.64 ft Fiber Optic Network Cable for Network Device, Transceiver, Server, Switch, Storage Adapter - First End: 1 x QSFP-DD Network - Second End: 4 x QSFP56 Network - 400 Gbit/s - LSZH - Multi-mode - Aqua - 1.0 - TAA Compliant
- SKU
- Q400G-4Q56G-AOC45MAO
- Category
- Connector Cables
MSRP$31,400.00
$17,877.07
Save 43%Back ordered
Back ordered — ships when restocked.
Genuine AddOn through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- Q400G-4Q56G-AOC45MAO
- Category
- Connector Cables
Overview
#N/A
Highlights
- Low latency DSP-free electronics-based CDR
- Multi-data rate up to 56.15 Gb/s per lane
- PAM4 modulation
- Single 3.3 V power supply
- Low power consumption: 7.6W on 400G end,2.3W on 100G end with all CDRs enabled
- QSFP-DD MSA compliant
- Commercial operating case temperature range: 0 to 70°C
- Hot pluggable
- RoHS/REACH compliant
- TUV-certified
- LSZH-rated cable
Specifications
| Cable Length | 147.64 ft |
|---|---|
| Product Type | Network Cable |
| Data Transfer Rate | 400 Gbit/s |
| Device Supported | Network Device, Transceiver, Server, Switch, Storage Adapter |
| Jacket Type | LSZH |
| Manufacturer Part Number | Q400G-4Q56G-AOC45MAO |
| Packaged Quantity | 1.0 |
| Limited Warranty | Lifetime |
| Features | AOC Technology, Lead-free, Bendable, CMIS 3.0 |
| Manufacturer | AddOn |
| Product Name | Fiber Optic Network Cable |
| Brand Name | AddOn |
| Environmentally Friendly | Yes |
| Cable Type | Fiber Optic |
| Connector Type on First End | QSFP-DD Network |
| Connector Type on Second End | QSFP56 Network |
| Fiber Optic Mode | Multi-mode |
| TAA Compliant | Yes |
| Product Color | Aqua |
| Color Family | Green |
| Connector on First End Details | 1 x QSFP-DD Network |
| Connector on Second End Details | 4 x QSFP56 Network |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS), Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
