AddOn MSA and TAA Compliant 200GBase-CU QSFP-DD 200G to 4xQSFP28 50G NRZ Direct Attach Cable (Passive Twinax, 2m)
AddOn

AddOn MSA and TAA Compliant 200GBase-CU QSFP-DD 200G to 4xQSFP28 50G NRZ Direct Attach Cable (Passive Twinax, 2m)

6.56 ft Twinaxial Network Cable for Network Device - First End: 1 x QSFP-DD Network - Male - Second End: 4 x QSFP28 Network - Male - 200 Gbit/s - Shielding - VW-1 - 28 AWG - 1 - TAA Compliant

SKU
Q200G-4Q28GPDAC2M-AO
Category
Connector Cables

MSRP$830.00

$472.54

Save 43%
Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine AddOn through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
Q200G-4Q28GPDAC2M-AO
Category
Connector Cables

Overview

This is an industry standard 200GBase-CU QSFP-DD 200G to 4xQSFP28 50G NRZ direct attach cable that operates over passive copper with a maximum reach of 2.0m (6.6ft). It has been programmed, uniquely serialized, and data-traffic and application tested to ensure it is 100% compliant and functional. This direct attach cable is TAA (Trade Agreements Act) compliant, and is built to comply with MSA (Multi-Source Agreement) standards. We stand behind the quality of our products and proudly offer a limited lifetime warranty.

Highlights

  • Compliant with QSFP-DD MSA Specification Rev 3.4
  • SFF-8679 electrical interface compliant
  • SFF-8636 management interface support
  • Compatible with IEEE 802.3bj, IEEE 802.3by, IEEE 802.3cd
  • Supports aggregate data rates of 100 and 200Gbps
  • I2C for EEPROM communication
  • Pull-to-release slide latch design
  • 28AWG through 32AWG cable
  • Excellent EMI/EMC performance 360-degree cable shield termination
  • Advantage dual side pre-solder automated assembly technologies

Specifications

Application/UsageIndustrial
Cable Length6.56 ft
Product TypeNetwork Cable
Data Transfer Rate200 Gbit/s
Device SupportedNetwork Device
Jacket TypeVW-1
Manufacturer Part NumberQ200G-4Q28GPDAC2M-AO
Packaged Quantity1
ShieldingYes
Limited WarrantyLifetime
Weight (Approximate)0.30 lb
FeaturesPassive
ManufacturerAddOn
Product NameTwinaxial Network Cable
Brand NameAddOn
Country of OriginUnited States/United Kingdom
Environmentally FriendlyYes
Cable TypeTwinaxial
Connector Type on First EndQSFP-DD Network - Male
Connector Type on Second EndQSFP28 Network - Male
American Wire Gauge28 AWG
Jacket MaterialPolyvinyl Chloride (PVC)
TAA CompliantYes
Connector on First End Details1 x QSFP-DD Network - Male
Connector on Second End Details4 x QSFP28 Network - Male
Product MaterialCopper
Connector Gender on First EndMale
Connector Gender on Second EndMale
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
